2 Specification
2.1

Feature List

Table 6 Feature Summary
Form Factor
Processor
Memory
cBC
Chipset
Audio
Ethernet
Graphics
Graphic Interfaces
Back Panel I/O
Connectors
Onboard I/O
Connectors
Other Features
BIOS
Power
Management
Security
Note
Some of the features mentioned in the above feature summary are optional. Check the article number of your module and compare it to the
options information list on page 11 of this user's guide to determine what options are available on your particular module.
Copyright © 2017 congatec AG
Based on Pico-ITX form factor (100 x 72 mm)
® th ®
Intel 5 Generation Intel Atom™, Pentium
Up to 4 Channels onboard LPDDR4 with up to 2400 MT/s, maximum system capacity 8 GB
Multi-stage watchdog, manufacturing and board information, board statistics, I2C bus, Power loss control
Integrated in the SoC
High Definition Audio Interface, Cirrus Logic CS4207
2x LAN Gbit / 100 Mbit / 10 Mbit, Intel Gigabit Ethernet i211 controller (i210 for industrial variants)
Intel ® Gen 9 HD Graphics with support for DirectX12, OpenGL 4.3, OpenCL 1.2, OpenGLES 3.0, MPEG2 full HW acceleration with H.264 with L5.2
decode and encode, HEVC (H.265), VP8, VP9, PAVP 2.0, HDCP 1.4 / 2.0, MVC and supports up to 3x independent displays
1x DP++, 1x DP via USB Type-C and either 1x LVDS (default) or 1x eDP 1.3
1x DisplayPort DP++ supports
- DP
DVI / HDMI 1.4 (requires external passive cable adapter)
-
2x LAN RJ45
1x LVDS
1x Backlight
2x Serial port connectors (RS232/RS485/RS422) (bottom side)
1x MicroSD slot (bottom side)
1x Standard SATA III interface (6 GB/s)
1x Power connector for 2.5" HDD (+5V)
1x miniPCIe or mSATA full size
1x HP OUT/SPDIF OUT/MIC connector (analog and digital audio)
1x Internal Power-IN (+12V)
Thermal and voltage monitoring, RTC Battery, congatec standard BIOS
AMI Aptio ® UEFI 5.x firmware, 16 MB SPI flash with congatec embedded BIOS features.
ACPI 4.0 compliant with battery support. Also supports Suspend to RAM (S3).
Ultra low standby power consumption.
Optional discrete Trusted Platform Module "TPM 1.2/2.0"; new AES Instructions for faster and better encryption.
® ®
and Celeron SoC.
1x USB 3.0 Type-C (Alternate mode)
2x USB 3.0
1x DC-In (only for commercial variants)
1x RTC battery connector
1x Fan connector
1x Dual USB 2.0 (internal)
3x Feature connectors
PA50m01
1x GPIO connector (offers 4 GPIs and 4 GPOs via cBC)
-
1x I2C/Watchdog connector (via cBC)
-
- 1x Connector for power, reset, sleep and LID buttons, as well as
power and SATA LEDs.
