Table 7 Measurement Description
The power consumption values were recorded during the following system states:
System State Description
S0: Minimum value Lowest frequency mode (LFM) with minimum core voltage during
desktop idle.
S0: Maximum value Highest frequency mode (HFM/Turbo Boost).
S0: Peak value Highest current spike during the measurement of "S0: Maximum
value". This state shows the peak value during runtime
Note
1. The fan and SATA drives were powered externally.
2. All other peripherals except the LCD monitor were disconnected before measurement.
Table 8 Power Consumption Values
The tables below provide additional information about the power consumption data for each of the conga-PA5 variants offered. The values are
recorded at various operating mode.
Part Memory H.W BIOS
No. Size Rev. Rev.
048100 8 GB TBD TBD
048101 4 GB TBD TBD
048102 4 GB TBD TBD
048120 8 GB TBD TBD
048121 4 GB TBD TBD
048123 4 GB TBD TBD
048110 8 GB TBD TBD
048111 4 GB TBD TBD
048112 4 GB TBD TBD
Note
With fast input voltage rise time, the inrush current may exceed the measured peak current.
Copyright © 2017 congatec AG
OS
(64-bit) Variant
Windows ® 10 Atom™ x7-E3950
®
Windows 10 Atom™ x5-E3940
Windows ® 10 Atom™ x5-E3930
® ®
Windows 10 Pentium N4200
Windows ® 10 Celeron ® N3350
Windows ® 10 Pentium ® N4200
Windows ® 10 Atom™ x7-E3950
Windows ® 10 Atom™ x5-E3940
Windows ® 10 Atom™ x5-E3930
Comment
The CPU was stressed to its maximum frequency.
The CPU was stressed to its maximum frequency.
Consider this value when designing the system's power supply to
ensure that sufficient power is supplied during worst case scenarios.
CPU Current (Amp.)
Cores Base / Burst S0: S0:
Freq. (GHz) Min Max
4 1.6/2.0 TBD TBD
4 1.6/1.8 TBD TBD
2 1.3/1.8 TBD TBD
4 1.1/2.5 TBD TBD
2 1.1/2.4 TBD TBD
4 1.1/2.5 TBD TBD
4 1.6/2.0 TBD TBD
4 1.6/1.8 TBD TBD
2 1.3/1.8 TBD TBD
PA50m01
S0:
Peak
TBD
TBD
TBD
TBD
TBD
TBD
TBD
TBD
TBD
