Pin
Signal
Pin
51
N.C.
52
53
GND
54
Connector Type
X10: PCIe mini card socket
Note
For the conga-PA5 to detect the type of card inserted as described in the mPCIe/mSATA specification, pin 43 of the mPCIe card must be
connected to ground. On mSATA card, this pin must not be connected. The miniPCIe extender can be used for miniPCIe half size cards.
Copyright © 2017 congatec AG
Signal
+3.3Vaux
GND
PA50m01
34/46
