Configuration

The default programming of the 4100ESi for NAC3 and the AUX POWER outputs is compatible with the
T-GEN 50. The T-GEN 50 requires some configuration for correct operation with 4100ESi.
These switch and link settings apply to T-GEN 50 software version1.7.
Table 2. T-GEN 50 Settings for NAC Operation
Alert to evacuate change over time
SW1 (TO) SW2 (T1)
OFF OFF
ON OFF
OFF ON
ON ON
OFF OFF
ON OFF
OFF ON
ON ON
Table 3. T-GEN 50 Switch Settings for NAC Operation
Switch Name
ALM I/P
SW 4
Supervision
SW 5 ALM I/P
SW 6
Evac Tone
SW 7
SW 8 Evac Message
Table 4. T-GEN 50 Link Settings for NAC Operation
Link Name
1 BIAS
2 MASTER
3 REC EN
4 TEST
5 SLAVE
6 SLAVE/MASTER MASTER.
FAULT=
7
DEF-/RELAY

More Power

If additional audio power is required, connect additional T-GEN 50 units to the 4100ESi power supply. The two
other AUX POWER terminals on the power supply can be used to power additional T GEN 50 units, if the
outputs are not being used to power other equipment, see Figure13. These additional T-GEN 50 units cannot
be fitted in the 15U 4100ESi cabinet; a separate expansion cabinet mounted adjacent to the 15U cabinet is
required. For information about available expansion cabinets and installation details, see Mounting the cabinet
in Chapter 3.
Configure additional T-GEN 50 units as slaves controlled by the first T-GEN 50 as master, see Figure13.
SW3 (T3) Setting on T-GEN 50
OFF 0 sec
OFF 30 sec
OFF 1 min
OFF 1.5 min
ON 3 min
ON 5 min
ON 10 min
ON Alert only
Setting on T-GEN 50
OFF (Supervision disabled).
OFF (Non-latching).
OFF.
OFF for AS 2220 tone.
ON for ISO 8210 + Keywords.
Off for Evac Message 1 or Field Recorded message.
ON for Evac Message 2 or Keywords only in ISO 8210.
Setting on T-GEN 50
Can be FITTED if a PA or background
Music is not required.
FITTED.
Fit to record message.
Fit for test tone during installation.
NOT FITTED.
RELAY.
