Appendix C Compatible actuating
devices

MX Addressable Devices

The 4100ESi supports a maximum of 250 MX devices on a loop, and 2000 points on a CPU.
The number of devices on an MX loop can be limited to less than 250 devices depending on the
characteristics and loading of the devices configured. Use the 4100Cost tool to validate a loop design.
MX Addressable Detectors
516.850.051.E 850PH Photoelectric Smoke and Heat detector
– SCI.
516.850.052.E 850P Photoelectric Smoke – SCI.
516.850.053.E 850H Heat detector – SCI.
516.600.054.E 850PC Photoelectric Smoke, Heat, CO detector
– SCI.
MX Addressable Field Devices
CP820 CP820 Call Point.
514.800.604.Y CP830 Call Point.
MIM800 MIM800 Monitored Input Module.
CIM800 CIM800 Contact Input Module.
RIM800 RIM800 Relay Output Module.
SNM800 SNM800 Sounder Notification Module.
DIM800 DIM800 Detector Input Module.
577.800.006 DDM800 Detector Device Module.
555.800.065 MIO800 Multi-I/O Module.
516.800.014 VIO800 VESDA Interface
545.800.004 LIM800 Loop Isolator Module.
MX Addressable Sounders and Beacons
516.800.957 LPSB3000 Sounder Base.
516.800.958 LPAV3000 Sounder-Beacon Base.
516.800.960 LPSY800R Symphonic Sounder Red.
516.800.961 LPSY800W Symphonic Sounder-White.
516.800.962 LPSY865 Symphonic Sounder IP65.
516.800.963 LPAV800R Symphonic Sounder
Beacon-Red.
516.800.964 LPAV800W Symphonic Sounder
Beacon-White.
516.800.965 LPAV865 Symphonic Sounder IP65.
Maximum number of
devices on a loop
250
250
250
250
Maximum number of
devices on a loop
250
250
250
250
250
250
250
7
125
125
250
Maximum number of
devices on a loop
191
87
147
147
147
76
76
76
80
