Introduction
Inspecting Contents
of Shipment
In this Publication
Specifications
©
2006 Tyco Safety Products Westminster, Westminster, MA 01441-0001 USA
All specifications and other information shown were current as of document revision date, and are subject to change without notice.
Tyco, Simplex, and the Simplex logo are trademarks of Tyco International Services AG or its affiliates in the U.S. and/or other countries.
This publication describes the installation procedures for the following PIDs:
•
4100-9607 Remote Annunciator w/ Flexible User Interface – Domestic
•
4100-9608 Remote Annunciator w/ Flexible User Interface - Canadian
•
4100-9609 Remote Annunciator w/ Flexible User Interface - International
•
4100-9610 Remote Annunciator
•
4100-9611 Basic Remote Annunciator
•
4100-9612 Basic Remote Annunciator w/ Flexible User Interface - Domestic
•
4100-9613 Basic Remote Annunciator w/ Flexible User Interface - Canadian
•
4100-9614. Basic Remote Annunciator w/ Flexible User Interface - International
IMPORTANT: Verify 4100U system programmer, executive, and slave software
compatibility when installing or replacing system components. Refer to
solution bulletin SB01014 for compatibility information.
Upon unpacking your Simplex product, inspect the contents of the carton for shipping damage. If
damage is apparent, immediately file a claim with the carrier and notify an authorized Simplex
product supplier.
This publication discusses the following topics:
Cautions and Warnings
Remote Annunciator Installation
Power Requirements (4100-9610 and 4100-9611)
Input Voltage
Input Current
Power Requirements (all models with Flexible User Interface)
Input Voltage
Input Current
Environmental Specifications
Operating Temperature
Humidity
4100U Remote Annunciators
Installation Instructions
Topic
19-33 VDC
87 mA standby or alarm
24 VDC
186 mA standby, 214 mA alarm
32° to 120° F (0° to 49° C)
Up to 93% relative humidity at 90° F (32° C)
See Page #
2
3
579-271
Rev. G
Advertisement
Table of Contents
Related Manuals for Simplex 4100U
Summary of Contents for Simplex 4100U
- Page 1 All specifications and other information shown were current as of document revision date, and are subject to change without notice. Rev. G Tyco, Simplex, and the Simplex logo are trademarks of Tyco International Services AG or its affiliates in the U.S. and/or other countries.
- Page 2 DO NOT INSTALL ANY SIMPLEX PRODUCT THAT APPEARS DAMAGED. Upon unpacking your Simplex product, inspect the contents of the carton for shipping damage. If damage is apparent, immediately file a claim with the carrier and notify your local Simplex product supplier.
- Page 3 4100-9610 remote annunciator is used when LED/Switch door modules are located in a transponder cabinet. A power supply (SPS, RPS etc.) is required. Other 4100U modules may be located within the transponder cabinet. The other three remote annunciators contain a Flexible User Interface, which has a large screen LCD.
- Page 4 Remote Annunciator Installation, (continued) Remote annunciators are made up of several modules, and each module has its own set of General Setup installation instructions. The figures below and on the next page show the general setup for each remote annunciator. Refer to the appropriate manuals to install specific modules. Manuals are found in the ship group for each module.
- Page 5 Remote Annunciator Installation (continued) Wiring for the The field-wiring to 4100-9611, -9612, -9613 and 4100-9614 Remote Annunciators is 24V power Remote Annunciator and RUI communications. Refer to Figure 3 for wiring information. Assembly Figure 3. Wiring for 4100-9611, 4100-9612, 4100-9613, and 4100-9614. TIC Assembly Used on the the Remote Annunciator...
- Page 6 Remote Annunciator Installation (continued) The 4100-0620 TIC Assembly is used on the 4100-9607, 4100-9608, 4100-9609, and 4100-9610 Wiring for the Basic remote annunciator. Refer to Figure 4 for wiring information. Annunciator Assembly Figure 4. Wiring for the Basic Annunciator TIC Assembly 579-271 Rev.
