User's Manual for Aeros and EasyMatch Essentials v 1.1
To stop the Continuous Read, press the Read button when the button is green..
▪
Auto Save Job
This selection will automatically save a job. Once this feature is selected, a dialog
box will be displayed to name the job. If there is no name for a job yet, the file
name will be default with the date, time, instrument and workspace.
▪
Index Bias Correction
This option allows the user to input a custom slope and intercept correction for
indices. The user can select any Index from the list of applicable indices and input
the desired Gain and Bias values. After selecting the required Indices, select the
Apply button to save the selected Indices values and update the Views accordingly.
The Bias-corrected Indices will be marked with * (eg: HCCI *) in the respective view
display.
To calculate the slope and bias correction, read a series of samples around the
target values of interest. Three methods can be used to provide corrected values:
1. One standard data point: In this case, the single data point is compared to
the expected value. The Gain remains at 1.0 and the Bias is corrected:
Bias= Expected Value- Measured Value
2. Two data points: In this case, the two readings are compared to the
expected values.
Bias Correction=Expected Value 1-(Measured Value 1*Gain)

Figure 42. Continuous Read

Figure 43. Auto Save Job

35
