MOUNTING DIMENSIONS
4.3

DIMENSIONS OF MR10 AND MR12, IP00

53 (2.09)
Ø12 (0.47)
Ø25 (0.98)
Ø25 (0.98)
Ø10 (0.39)
Ø9 (0.35)
Ø9 (0.35)
Fig. 5: Dimensions without the options module [mm (in)]
A. The EMC jumper
B. M8 GND pin
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
980 (38.58)
870 (34.25)
930 (36.61)
876 (34.49)
Ø9 (0.35)
C
Ø13 (0.51)
24 (0.94)
43 (1.69)
C. The control unit
432 (17.01)
418 (16.46)
412 (16.22)
383 (15.08)
348 (13.70)
483 (19.02)
Ø30 (1.18)
37 (1.46)
VACON · 23
A
B
4
