TECHNICAL DATA, VACON® 100 INDUSTRIAL
Table 37: The recommended brake resistor types and the calculated resistance of the drive,
208-240 V
Enclosure size
MR8
MR9
Table 38: The recommended brake resistor types and the calculated resistance of the drive,
380-500 V
Enclosure size
MR8
MR9
MR10
MR12
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
Duty cycle Type of brake resistor
Light duty BRR 0105 LD 5
Heavy duty BRR 0105 HD 5
Light duty BRR 0300 LD 5
Heavy duty BRR 0300 HD 5
Duty cycle Type of brake resistor
Light duty BRR 0105 LD 5
Heavy duty BRR 0105 HD 5
Light duty BRR 0300 LD 5
Heavy duty BRR 0300 HD 5
Light duty BRR 0520 LD 5
Heavy duty BRR 0520 HD 5
Light duty BRR 0520 LD 5
Heavy duty BRR 0520 LD 5
VACON · 107
Resistance [Ω]
6.5
6.5
3.3
3.3
Resistance [Ω]
6.5
6.5
3.3
3.3
1.4
1.4
2 x 1.4
2 x 1.4
