REMOVING THE PACKAGING AND LIFTING THE AC DRIVE

3.4.1

WEIGHT OF THE AC DRIVE

The weights of AC drives of different enclosure sizes are very different. It can be necessary
for you to use a lifting device to move the drive from its package.
Table 4: The weight of the AC drive, MR8-MR12
Enclosure size or item
MR8 IP00 drive module
MR9 IP00 drive module
MR10 IP00 drive module
MR10 IP00 drive module and the options module with the brake
chopper
MR10 IP00 drive module and the options module with the brake
chopper and the common mode filter
MR10 IP00 drive module and the options module with the brake
chopper, the common mode filter, and the du/dt filter
MR10 IP00 drive module and the options module with AC fuses and
fuse switch (+CIFD)
MR12 IP00 drive module
MR12 IP00 drive module and the options module with the brake
chopper
MR12 IP00 drive module and the options module with the brake
chopper and the common mode filter
MR12 IP00 drive module and the options module with the brake
chopper, the common mode filter, and the du/dt filter
MR12 IP00 drive module and the options module with AC fuses and
fuse switch (+CIFD)
3.4.2

LIFTING THE IP00 DRIVE MODULE

The AC drive is delivered horizontally on a wooden pallet. Open the package only when you
install the drive. Do not keep the drive in storage in the vertical position.
LIFTING THE IP00 DRIVE MODULE, MR8 AND MR9
1 Remove the drive from the pallet where it was
bolted to.
2 Use a lifting device that is sufficiently strong for the
weight of the drive.
3 Put the lifting hooks symmetrically in a minimum of
2 holes.
3
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
RECEIVING THE DELIVERY
Weight [kg] Weight [lb]
62 137
97 214
221 487
252 556
258 569
289 637
332 732
442 974
504 1111
516 1138
578 1274
570 1257
