Vacon 100 Safety Manual

Vacon 100 Safety Manual

Optbj sto and atex option board
Hide thumbs Also See for 100:
Table of Contents

Advertisement

Quick Links

See also: Technical Manual , User Manual
vacon 100
®
ac drives
optbj
sto and atex option board
safety manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vacon 100

Summary of Contents for Vacon 100

  • Page 1 100 ® ac drives optbj sto and atex option board safety manual...

  • Page 3: Table Of Contents

    References .........................9 Installation of OPTBJ board ................10 OPTBJ board layout..................13 OPTBJ board jumpers......................13 STO jumpers on the Vacon 100 drive ................14 STO and SS1 safety functions .................15 Safe Torque Off (STO) principle ..................15 Safe Stop 1 (SS1) Principle ....................18 Technical details ......................20 5.3.1 Response times........................20...

  • Page 4: Approvals

    • 2 Approvals PPROVALS Tel. +358 (0) 201 2121 • Fax +358 (0)201 212 205...
  • Page 5 Approvals vacon • 3 24-hour support +358 (0)201 212 575 • Email: vacon@vacon.com...
  • Page 6 • 4 Approvals Tel. +358 (0) 201 2121 • Fax +358 (0)201 212 205...
  • Page 7 Approvals vacon • 5 24-hour support +358 (0)201 212 575 • Email: vacon@vacon.com...
  • Page 8 • 6 Approvals Tel. +358 (0) 201 2121 • Fax +358 (0)201 212 205...
  • Page 9 Approvals vacon • 7 24-hour support +358 (0)201 212 575 • Email: vacon@vacon.com...

  • Page 10: General

    This document covers the OPTBJ option board 70CVB01380 functionality together with Vacon 100 Control board 70CVB01582. The OPTBJ option board together with Vacon 100 control board provides the following safety func- tions with Vacon 100 products. The following safety-related abbreviations and expressions have been used in this manual:...

  • Page 11: References

    All safety functions of the OPTBJ board are described in this manual. ** VTT = Technical Research Centre of Finland References Vacon 100 Installation and Application manuals are downloadable at http://drives.danfoss.com/ knowledge-center/technical-documentation/. 24-hour support +358 (0)201 212 575 • Email: vacon@vacon.com...

  • Page 12: Installation Of Optbj Board

    Vacon 100 is disconnected from mains. 9000.emf Slot coding 3040.emf NOTE: Incompatible boards cannot be installed on Vacon 100. Compatible boards have a slot coding that enable the placing of the board (see above) Tel. +358 (0) 201 2121 • Fax +358 (0)201 212 205...
  • Page 13 OPTBJ cable to the frame of the AC drive. NOTE! Shielded cable must be used. NOTE! Grounding must be done according to best practice. Grounding clamp for control cable 11574A_uk 24-hour support +358 (0)201 212 575 • Email: vacon@vacon.com...
  • Page 14 • 12 Installation of OPTBJ board Unless already done for the other control cables, cut free the opening on the AC drive cover for the OPTBJ cable (protection class IP21). NOTE: Cut the opening on the side of the slot E!

  • Page 15: Optbj Board Layout

    To activate the OPTBJ board, you must take the three-pin jumper from the drive control board and place it to the OPTBJ board jumper X10. See the next chapter for more information. NOTE! If there are problems with the jumpers, see chapter 7.1! 24-hour support +358 (0)201 212 575 • Email: vacon@vacon.com...

  • Page 16: Sto Jumpers On The Vacon 100 Drive

    STO jumpers on the Vacon 100 drive STO JMP 3049A_00 Figure 3. STO jumper location on Vacon 100. Open the main cover and the inner cover to reveal the jumper. Tel. +358 (0) 201 2121 • Fax +358 (0)201 212 205...

  • Page 17: Sto And Ss1 Safety Functions

    CAUTION! The information in this manual provides guidance on the use of the safety functions that OPTBJ option board provides together with Vacon 100 con- trol board. This information is in compliance with accepted practice and regula- tions at the time of writing.
  • Page 18 Atex Safety Thermistor Function Atex Safety Function STO1 STO2 POWER UNIT Hardware Hardware STO 1 STO 2 11575A_uk Figure 4.STO principle with OPTBJ board and Vacon 100 control board MR4-10 Tel. +358 (0) 201 2121 • Fax +358 (0)201 212 205...
  • Page 19 SLAVE MASTER POWER UNIT POWER UNIT Hardware Hardware Hardware Hardware STO 1 STO 2 STO 1 STO 2 11654_uk Figure 5.STO principle with OPTBJ board and Vacon 100 control board MR12 24-hour support +358 (0)201 212 575 • Email: vacon@vacon.com...

  • Page 20: Safe Stop 1 (Ss1) Principle

    STO safety function. These two subsystems combined compose the Safe Stop 1 safety function as shown in Figure 7. Safe Stop 1 (SS1) Time Delayed Safety Relay Vacon 100 Safe Torque Off (STO) Subsystem Subsystem Safety Relay 11579_uk Figure 7.
  • Page 21 • A separate digital output from the safety relay is connected to a general digital input of the Vacon 100 drive. The general digital input must be programmed to execute the drive stop command and initiates the drive stop function without a time delay (must be set to "stop by ramp") and causes motor deceleration.

  • Page 22: Technical Details

    • 20 STO and SS1 safety functions Technical details 5.3.1 Response times Activation Safety function activation time time Safe Torque Off (STO) < 20 ms 500 ms Table 1. STO response times 5.3.2 Connections In addition to the STO inputs, the board contains also a thermistor input. If the thermistor input is not used, it must be disabled.

  • Page 23: Relay Output

    HFT = 1 HFT = 1 SIL 3 SIL 3 IEC 61508:2010, )= 2.2x10 )= 2.7x10 Low Demand Mode = 20 years = 20 years HFT = 1 HFT = 1 24-hour support +358 (0)201 212 575 • Email: vacon@vacon.com...
  • Page 24 • PSR-SCP-24DC/ESD/5X1/1X2/300 or • PSR-SPP-24DC/ESD/5X1/1X2/300 See manufacturer user manual for more information regarding the time delayed safety relay. PSR-SC/PP-24DC/ESD/5X1/1X2/300 safety- related data from user manual and certificate: Vacon 100 STO safety-related data: EN 61800-5-2 IEC 61 508 SIL 2 SIL 3...

  • Page 25: Wiring Examples

    • Giving a valid start command will start running the motor. NOTE! The Vacon 100 default application software uses edge-sensitive start as default start com- mand, for preventing unexpected startup from STO state. 24-hour support +358 (0)201 212 575 • Email: vacon@vacon.com...
  • Page 26 • Giving a valid start command will start running the motor. NOTE! The Vacon 100 default application software uses edge-sensitive start as default start com- mand, for preventing unexpected startup from STO state. NOTE! For EN 60204-1 emergency stop according to stop category 0, use the emergency stop but- ton.
  • Page 27 Giving a valid start command will start running the motor More information on the safety relay module may be found in the safety relay documentation. NOTE! The Vacon 100 default application software uses edge-sensitive start as default start com- mand, for preventing unexpected startup from STO state.

  • Page 28: Commissioning

    • 26 Commissioning OMMISSIONING NOTE! The use of STO, SS1 or other safety functions does not itself ensure safety. Always make sure that the safety of the entire system is confirmed. NOTE! The user is responsible for excluding faults in the external wiring.

  • Page 29: Checklist For Commissioning The Optbj Board

    Have only approved units and parts been used? Is the Vacon 100 control board 70CVB01582? (See the sticker on the Va- con 100 control board, or “Drive Info” in Vacon Live) Is the Vacon 100 system software version FW0072V002, or newer?

  • Page 30: Testing The Safe Torque Off (Sto) Or Safe Stop 1 (Ss1) Safety Functions

    • 28 Commissioning Testing the Safe Torque Off (STO) or Safe Stop 1 (SS1) safety functions NOTE! Before testing the STO or SS1 safety functions, make sure that the checklist (Chapter 6.2) is inspected and completed. NOTE! After connecting the board ALWAYS make sure that the STO or SS1 safety functions are working properly by testing them before operating the system.

  • Page 31: Maintenance

    • Restart the drive. Safety configuration between the control board and • Change the OPTBJ board if nec- OPTBJ option board. essary. • Should the fault re-occur, con- tact the distributor near to you. 24-hour support +358 (0)201 212 575 • Email: vacon@vacon.com...
  • Page 32 STO tact the distributor near to you. inputs are in a different state for Deliver the fault report to the more than 100 ms. distributor, see fault details for more information. • Restart the drive. • If the restart does not help,...

  • Page 33: Thermistor Function (Atex)

    STO1+(OPTBJ:1), STO2+(OPTBJ:3) are to be connected to +24V (for ex- ample, pin 6 in Vacon 100 control board). STO1-(OPTBJ:2). STO2- (OPTBJ:4) are to be connected to GND (for example, pin 7 or 13 on Vacon 100 control board).
  • Page 34 FIN-65381 Vaasa Finland hereby declare that the product Product name: Vacon OPTBJ (70CVB01380) to be used with Vacon 100 control unit (70CVB001582) Marking of the equipment: has been designed in conformity with the requirements of the Council directive for explosive atmospheres, 94/9/EC of March 1994 according to following standards.
  • Page 35 Thermistor Function Atex Safety Function STO1 STO2 POWER UNIT Hardware Hardware STO 1 STO 2 11575A_uk Figure 9. Thermistor function principle in Vacon 100 AC drive with the OPTBJ board, MR4-10 24-hour support +358 (0)201 212 575 • Email: vacon@vacon.com...
  • Page 36 POWER UNIT POWER UNIT Hardware Hardware Hardware Hardware STO 1 STO 2 STO 1 STO 2 11654_uk Figure 10.STO principle with OPTBJ board and Vacon 100 control board MR12 Tel. +358 (0) 201 2121 • Fax +358 (0)201 212 205...

  • Page 37: Technical Data

    The thermistor supervision circuit meets the requirements in the ATEX directive by directly activat- ing the "STO" safety function of the Vacon 100 (See Figure 9) and thus provides a reliable, software and parameter independent way of preventing the energy supply to the motor.

  • Page 38: Short Circuit Monitoring

    • 36 Thermistor function (ATEX) 8.1.4 Short circuit monitoring The thermistor inputs TI1+ and TI1- are monitored for short circuit. If a short circuit is detected, the drive modulation is disabled within 20ms, Fault 30, Safety diagnostic (subcode 522) is generated.

  • Page 39: Commissioning

    The table below shows the normal fault / warning, generated when thermistor input is active Fault code Fault Explanation Correcting measures Atex-thermistor has detected Atex-thermistor overtemperature. See the fault table in chapter 6.1. 24-hour support +358 (0)201 212 575 • Email: vacon@vacon.com...
  • Page 40 Document ID: Vacon Ltd Member of the Danfoss Group Rev. D Runsorintie 7 65380 Vaasa Sales code: DOC-OPTBJ+DLUK Finland...
