MOUNTING DIMENSIONS
4
MOUNTING DIMENSIONS
4.1
DIMENSIONS OF MR8, IP00
10
(0.37)
Ø9 (0.35)
Ø9
(0.35)
Ø22
(0.87)
18
(0.71)
Fig. 3: The dimensions of the AC drive, MR8, [mm (in)]
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
663 (26.10)
Ø11 (0.43)
683 (26.89)
794 (31.26)
VACON · 21
11
(0.43)
A
15
(0.59)
4
