Mains Voltage 525-690 V; Overload Capability - Vacon 100 Flow Installation Manual

TECHNICAL DATA, VACON® 100 FLOW
10.1.3

MAINS VOLTAGE 525-690 V

Table 46: The power ratings of VACON
Enclosure Drive type
size
MR8 0080
0100
0125
MR9 0144
0170
0208
MR10 0261
0325
0385
0416*
MR12 0460
0520
0590
0650
0750*
0820*
10.1.4

OVERLOAD CAPABILITY

The low overload means that if 110% of the continuous current (I
every 10 minutes, the remaining 9 minutes must be approximately 98% of I
make sure that the output current is not more than I
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
100 FLOW in mains voltage 525-690 V, 50-60 Hz, 3~
®
Loadability
Continuous Input
current current I
Lin
I [A] [A]
Lout
80.0 90.0
100.0 106.0
125.0 127.0
144.0 156.0
170.0 179.0
208.0 212.0
261.0 272.0
325.0 330.0
385.0 386.0
416.0 415.0
460.0 477.0
520.0 532.0
590.0 597.0
650.0 653.0
750.0 747.0
820.0 813.0
10% Max
overload current I
S
current [A] 2s
88.0 124.0
110.0 160.0
137.5 200.0
158.4 250.0
187.0 288.0
228.8 340.0
287.1 416.0
357.5 522.0
423.5 650.0
457.6 770.0
506.0 832.0
572.0 920.0
649.0 1040.0
715.0 1180.0
825.0 1300.0
902.0 1300.0
) is required for 1 minute
L
during the duty cycle.
L
VACON · 117
Motor shaft power
600 V 690 V
mains mains
10% 10%
overload overload
40°C [hp] 40°C [kW]
75.0 75.0
100.0 90.0
125.0 110.0
150.0 132.0
- 160.0
200.0 200.0
250.0 250.0
300.0 315.0
400.0 355.0
450.0 400.0
450.0 450.0
500.0 500.0
600.0 560.0
650.0 630.0
700.0 710.0
800.0 800.0
or less. This is to
L
10
