VACON · 22
A. An optional main connector cover for the
cabinet installation
4.2
DIMENSIONS OF MR9, IP00
Ø9 (0.35)
14 (0.55)
Fig. 4: The dimensions of the AC drive, MR9 [mm (in)]
A. An optional main connector cover for the
cabinet installation
4
810 (31.89)
841 (33.09)
Ø22 (0.87)
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
MOUNTING DIMENSIONS
50 (1.97)
Ø9 (0.35)
17 (0.65)
130 (5.12)
A
