VACON · 34
5.1.3

GENERAL INFORMATION ABOUT THE INSTALLATION, MR12

PE 2L1 2L22L3
B
PE L1 L2 L3
DC+ DC- PE U/T1
C
PE
Fig. 15: The main circuit diagram, MR12 without the options module and options
A. The power unit 1
B. The power unit 2
C. The optional external power connection
blocks (+PCTB)
D. The control unit
The minimum length of motor cables from the power unit to a common point of coupling is
10 m. When a du/dt filter is used, the cables can be less than 10 m long.
The optional external power connection block enables the connection of 3 motor cables to 1
terminal. It is also easier to connect large motor cables when you have this option.
The external power connection block is a loose option, install it near the IP00 drive module.
The cables between the motor cable terminals of the drive and the external power
connection block are not included in the delivery.
5
COM
STO
V/T2 W/T3
U/ V/ W/
T1 T2 T3
PE U1
M
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
PE 1L1 1L2 1L3
PE L1 L2 L3
A
DC+ DC- PE U/T1 V/T2
C
U/
T1
PE
V1 W1
E
E. Symmetrical motor cabling. The cables
must have the same length from the
power unit to a common point of
coupling.
INSTALLATION INTO CABINET
D
COM
STO
W/T3
V/ W/
T2 T3
