RECEIVING THE DELIVERY
3.2

TYPE DESIGNATION CODE

The type designation code is made of standard codes and option codes. Each part of the type
designation code agrees to the data in your order. The code can have this format, for
example:
VACON0100-3L-0385-5-FLOW+IP00
Table 3: The description of the parts in the type designation code
Code
VACON0100
3L
0385
5
FLOW
+IP00
3.3

THE CONTENTS OF THE DELIVERY

The contents of the delivery, MR8-MR9
The IP00 drive module with an integrated control unit
•
An accessories bag
•
Installation Manual, Application Manual and manuals for the options that you ordered
•
The contents of the delivery, MR10
The IP00 drive module with an integrated control unit
•
An accessories bag
•
The options module, if you ordered it with options
•
Installation Manual, Application Manual and manuals for the options that you ordered
•
The contents of the delivery, MR12
The IP00 drive module: 2 power units, 1 of them with an integrated control unit
•
An accessories bag
•
The options module, if you ordered it with options
•
A DC link cable
•
A set of optical fibre cables
•
Installation Manual, Application Manual and manuals for the options that you ordered
•
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
Description
The product family: VACON0100 = the VACON
Input/Function: 3L = A 3-phase input
The drive rating in amperes. For example, 0385 = 385 A
The mains voltage:
2 = 208-240 V
5 = 380-500 V
7 = 525-690 V
The product:
(empty) = The VACON 100 INDUSTRIAL AC drive
®
FLOW = The VACON ® 100 FLOW AC drive
The enclosure class of the AC drive is IP00.
VACON · 15
100 product family
®
