Anybus Object (01h)
Category
Basic
Object Description
This object assembles all common Anybus data, and is described thoroughly in the general Anybus
CompactCom 40 Software Design Guide.
Instance attribute #16 has to be set to 0002h during SETUP state to enable Transparent
Ethernet functionality.
Supported Commands
Object:
Instance:
Object Attributes (Instance #0)
(Consult the general Anybus CompactCom 40 Software Design Guide for further information.)
Instance Attributes (Instance #1)
Basic
#
Name
1
Module type
-
2... 11
12
LED colors
-
13...
15
16
GPIO configuration
Anybus CompactCom 40 EtherNet/IP Transparent Ethernet Network Guide
Get_Attribute
Get_Attribute
Set_Attribute
Get_Enum_String
Access
Type
Get
UINT16
-
-
Get
struct of:
UINT8 (LED1A)
UINT8 (LED1B)
UINT8 (LED2A)
UINT8 (LED2B)
-
-
Get/Set
UINT16
Value
0403h (Standard Anybus CompactCom 40)
Consult the general Anybus CompactCom 40 Software
Design Guide for further information.
Value: Color:
01h Green
02h Red
01h Green
02h Red
Consult the general Anybus CompactCom 40 Software
Design Guide for further information.
Configuration of the host interface GIO pins. To enable
Transparent Ethernet, this attribute has to be set to
0002h during SETUP state.
59 (144)
SCM-1202-019-EN 1.6
