Anybus CompactCom 40 Network Manual page 57

CIP Objects
# Name Access
6 Interface Get/Set
Control
Control Bits
Forced Inter-
face Speed
7 Interface Get
Type
8 Interface Get
State
9 Admin State Get/Set
10 Interface Get
Label
11 Interface Get
Capability
Capability
Bits
Speed/Du-
plex Options
• Support for attribute #6 can be disabled by implementing attribute #9 in the EtherNet/IP Host Object
(F8h). see EtherNet/IP Host Object (F8h), p. 88
• Support for attribute #8 can be disabled by implementing the port state attributes (#12 or #13) in the
Ethernet Host object (F9h) see
Anybus CompactCom 40 EtherNet/IP Transparent Ethernet Network Guide
Type Value
Struct of:
-
WORD
-
UINT
-
USINT
-
USINT
-
USINT
—
SHORT_
STRING
-
Struct of:
-
DWORD
-
Struct of:
-
USINT
-
Array of Struct
of:
-
UINT
-
USINT
Ethernet Host Object (F9h), p. 97
Comments
Interface control bits
Speed at which the interface shall be forced to operate.
Returns 'Object state Conflict' if auto-negotiation is
enabled
See table "Interface State" below.
See table "Interface Type" below.
See table "Admin State" below.
See table "Interface Label" below.
Indication of the capabilities of the interface
Interface capabilities, other than speed/duplex
See table "Interface Capability" below.
Indicates speed/duplex pairs supported in the Inter-
face Control Attribute
Speed/duplex array count
Speed/duplex array
Interface speed
Interface Duplex Mode
0 = half duplex
1 = full duplex
2 - 255 = Reserved
