CIP Objects
7.9

QoS Object (48h)

Category
Extended
Object Description
Quality of Service (QoS) is a general term that is applied to mechanisms used to treat traffic streams with dif-
ferent relative priorities or other delivery characteristics. Standard QoS mechanisms include IEEE 802.1D/Q
(Ethernet frame priority) and Differentiated Services (DiffServ) in the TCP/IP protocol suite.
The QoS Object provides a means to configure certain QoS related behaviors in EtherNet/IP devices.
The object is required for devices that support sending EtherNet/IP messages with nonzero DiffServ code
points (DSCP), or sending EtherNet/IP messages in 802.1Q tagged frames.
Supported Services
Class:
Instance:
Class Attributes
# Name Access
1 Revision Get
Instance Attributes
Attributes #1–4 and #6–7 an be customized by implementing the EtherNet/IP Host Object, see
Host Object (F8h), p. 88
# Name Access
1 802.1Q Tag Set
Enable
4 DSCP Set
Urgent
5
DSCP Set
Scheduled
6 DSCP High Set
7 DSCP Low Set
8 DSCP Set
Explicit
Anybus CompactCom 40 EtherNet/IP Transparent Ethernet Network Guide
Get_Attribute_Single
Get_Attribute_Single
Set_Attribute_Single
Type Value
UINT 0001h (Object revision)
Type Value/Description
USINT Enables or disables sending 802.1Q frames.
Value:
0
1
USINT CIP transport class 1 messages with priority Urgent
Default: 55
USINT CIP transport class 1 messages with priority Scheduled
Default: 47
USINT CIP transport class 1 messages with priority High
Default: 43
USINT CIP transport class 1 messages with priority Low
Default: 31
USINT CIP UCMM and CIP class 3
Default: 27
Contents:
Disabled (Default)
Enabled
41 (144)
EtherNet/IP
SCM-1202-019-EN 1.6
