Anybus CompactCom 40 Network Manual page 70

Anybus Module Objects
Instance Attributes (Instances #13 - #15)
(Reserved)
Instance Attributes (Instance #16, MDI 1 Settings )
This instance holds the settings for MDI/MDIX 1. Changes have immediate effect.
# Name
1 Name
2 Data type
3 Number of elements
4 Descriptor
5 Value
5
Configured Value
Instance Attributes (Instance #17, MDI 2 Settings )
This instance holds the settings for MDI/MDIX 2. Changes have immediate effect.
# Name
1 Name
2 Data type
3 Number of elements
4 Descriptor
5 Value
5 Configured Value
Instance Attributes (Instances #18 and #19)
These instances are reserved for future attributes.
Anybus CompactCom 40 EtherNet/IP Transparent Ethernet Network Guide
Access Data Type Description
Get Array of
"MDI 1"
CHAR
Get UINT8 08h (= ENUM)
Get UINT8 01h (one element)
Get UINT8 07h (read/write/shared access)
Get/Set ENUM Value (ENUM):
00h
01h
02h
Get ENUM Holds the configured value, which will be written to attribute #5
after the module has been reset.
Value (ENUM):
00h
01h
02h
Access Data Type Description
Get Array of "MDI 2"
CHAR
Get UINT8 08h (= ENUM)
Get UINT8 01h (one element)
Get UINT8 07h (read/write/shared access)
Get/Set ENUM Value (ENUM):
00h
01h
02h
Get ENUM Holds the configured value, which will be written to attribute #5
after the module has been reset.
Value (ENUM):
00h
01h
02h
String: Meaning:
"Auto" (default)
"MDI"
"MDIX"
String: Meaning:
"Auto"
"MDI"
"MDIX"
String: Meaning:
"Auto" (default)
"MDI"
"MDIX"
String: Meaning:
"Auto"
"MDI"
"MDIX"
SCM-1202-019-EN 1.6
68 (144)
