CIP Objects
Interface Label
This attribute is configurable via the EtherNet/IP Host Object, see page
Instance Value
1 Port 1
2 Port 2
3 Internal
Interface Type
Value Description
Instance
1 2 Twisted-pair
2 2 Twisted-pair
3 1 Internal interface
Interface Capability
Name Description
Bit
0 Manual set- Indicates whether or not the device requires a reset to apply
ting requires changes made to the Interface Control attribute (#6).
reset
0
1
1 Auto- 0
negotiate
1
2 Auto-MDIX 0
1
3 Manual 0
speed/duplex
1
4 - 31 Reserved Shall be set to 0
Anybus CompactCom 40 EtherNet/IP Transparent Ethernet Network Guide
Indicates that the device automatically applies
changes made to the Interface Control attribute (#6)
and, therefore, does not require a reset in order for
changes to take effect. This bit shall have this value
when the Interface Control attribute (#6) is not
implemented.
1 = Indicates that the device does not automatically
apply changes made to the Interface Control attribute
(#6) and, therefore, will require a reset in order for
changes to take effect.
Note: this bit shall also be replicated in the Interface
Flags attribute (#2), in order to retain backwards com-
patibility with previous object revisions.
Indicates that the interface does not support link auto-
negotiation
Indicates that the interface supports link auto-
negotiation
Indicates that the interface does not support auto
MDIX operation
Indicates that the interface supports auto MDIX
operation
Indicates that the interface does not support manual
setting of speed/duplex. The Interface Control attrib-
ute (#6) shall not be supported.
Indicates that the interface supports manual setting of
speed/duplex via the Interface Control attribute (#6)
88
Implementation
Return 0
0 for internal interface, 1 for external
interfaces
0 for internal interface, 1 for external
interfaces
0 for internal interface, 1 for external
interfaces
Return 0
