Anybus CompactCom 40 Network Manual page 66

Anybus Module Objects
Instance Attributes (Instance #3, IP Address)
Value is used after module reset.
# Name
1 Name
2 Data type
3 Number of elements
4 Descriptor
5 Value
6 Configured Value
Instance Attributes (Instance #4, Subnet Mask)
Value is used after module reset.
# Name
1 Name
2 Data type
3 Number of elements
4 Descriptor
5 Value
6 Configured Value
Instance Attributes (Instance #5, Gateway Address)
Value is used after module reset.
# Name
1 Name
2 Data type
3 Number of elements
4 Descriptor
5 Value
6 Configured Value
Anybus CompactCom 40 EtherNet/IP Transparent Ethernet Network Guide
Access Data Type Description
Get Array of "IP address"
CHAR
(Multilingual, see page 70)
Get UINT8 04h (= UINT8)
Get UINT8 04h (four elements)
Get UINT8 07h (read/write/shared access)
Get/Set Array of If read, the actual value will be received. If written, the written
UINT8 value is reflected in attribute #6 until a reset.
Valid range: 0.0.0.0 - 255.255.255.255 (Default =0.0.0.0)
Get Array of Holds the configured value, which will be written to attribute #5
UINT8 after the module has been reset.
Valid range: 0.0.0.0 - 255.255.255.255 (Default =0.0.0.0)
Access Data Type Description
Get Array of "Subnet mask"
CHAR
(Multilingual, see page 70)
Get UINT8 04h (= UINT8)
Get UINT8 04h (four elements)
Get UINT8 07h (read/write/shared access)
Get/Set Array of If read, the actual value will be received. If written, the written
UINT8 value is reflected in attribute #6 until a reset.
Valid range: 0.0.0.0 - 255.255.255.255 (Default =0.0.0.0)
Get Array of Holds the configured value, which will be written to attribute #5
UINT8 after the module has been reset.
Valid range: 0.0.0.0 - 255.255.255.255 (Default =0.0.0.0)
Access Data Type Description
Get Array of "Gateway"
CHAR
(Multilingual, see page 70)
Get UINT8 04h (= UINT8)
Get UINT8 04h (four elements)
Get UINT8 07h (read/write/shared access)
Get/Set Array of If read, the actual value will be received. If written, the written
UINT8 value is reflected in attribute #6 until a reset.
Valid range: 0.0.0.0 - 255.255.255.255 (Default =0.0.0.0)
Get Array of Holds the configured value, which will be written to attribute #5
UINT8 after the module has been reset.
Valid range: 0.0.0.0 - 255.255.255.255 (Default =0.0.0.0)
64 (144)
SCM-1202-019-EN 1.6
