Anybus Module Objects
11.2

Anybus Object (01h)

Category
Basic
Object Description
This object assembles all common Anybus data, and is described thoroughly in the general Anybus
CompactCom 40 Software Design Guide.
Supported Commands
Object:
Instance:
Object Attributes (Instance #0)
(Consult the general Anybus CompactCom 40 Software Design Guide for further information.)
Instance Attributes (Instance #1)
Basic
# Name
1 Module type
-
2... 11
12 LED colors
-
13...
16
Extended
# Name
17 Virtual attributes
18 Black list/White list
19 Network time
Anybus CompactCom 40 EtherNet/IP Network Guide
Get_Attribute
Get_Attribute
Set_Attribute
Get_Enum_String
Access Type
Get UINT16
- -
Get struct of:
UINT8 (LED1A)
UINT8 (LED1B)
UINT8 (LED2A)
UINT8 (LED2B)
- -
Access Type
-
Get/Set
Get/Set
Get UINT64
Value
0403h (Standard Anybus CompactCom 40)
Consult the general Anybus CompactCom 40 Software
Design Guide for further information.
Value: Color:
01h Green
02h Red
01h Green
02h Red
Consult the general Anybus CompactCom 40 Software
Design Guide for further information.
Value
Consult the general Anybus CompactCom 40 Software
Design Guide for further information.
0 (Not supported)
108 (218)
