CIP Objects
7.14

TCP/IP Interface Object (F5h)

Category
Extended
Object Description
This object provides the mechanism to configure the TCP/IP network interface of the module. It groups the
TCP/IP-related settings in one instance for each TCP/IP capable communications interface.
See also ..
• Communication Settings, p. 12
• Network Configuration Object (04h), p. 63
Supported Services
Class:
Instance:
Class Attributes
# Name Access
1 Revision Get
2 Max Get
instance
3 Number of
Get
instances
6 Maximum ID Get
Number
Class
Attributes
7 Maximum ID
Get
Number In-
stance
Attributes
Anybus CompactCom 40 EtherNet/IP Transparent Ethernet Network Guide
(Anybus Module Object)
Get_Attribute_All
Get_Attribute_Single
Get_Attribute_All
Get_Attribute_Single
Set_Attribute_Single
Type Value
UINT 0004h (Object revision)
UINT 1 (Maximum instance number)
UINT 1 (Number of instances)
UINT 7 (The attribute number of the last implemented class attribute)
UINT 13 (The attribute number of the last implemented instance attribute)
50 (144)
SCM-1202-019-EN 1.6
