Anybus Module Objects
Instance Attributes (Instance #8 Ethernet Communication Settings 2)
Changes have immediate effect.
# Name
1 Name
2 Data type
3 Number of elements
4 Descriptor
5 Value
6 Configured Value
Instance Attributes (Instance #9, DNS1)
This instance holds the address to the primary DNS server. Changes are valid after reset.
# Name
1 Name
2 Data type
3 Number of elements
4 Descriptor
5 Value
6 Configured Value
Anybus CompactCom 40 EtherNet/IP Transparent Ethernet Network Guide
Access Data Type Description
Get Array of "Comm 2"
CHAR
(Multilingual, see page 70)
Get UINT8 08h (= ENUM)
Get UINT8 01h (one element)
Get UINT8 07h (read/write/shared access)
Get/Set ENUM Value
00h
01h
02h
03h
04h
Get ENUM Holds the configured value, which will be written to attribute #5
after the module has been reset.
Value
00h
01h
02h
03h
04h
Access Data Type Description
Get Array of "DNS1"
CHAR
(Multilingual, see page 70)
Get UINT8 04h (= UINT8)
Get UINT8 04h (four elements)
Get UINT8 07h (read/write/shared access)
Get/Set Array of If read, the actual value will be received. If written, the written
UINT8 value is reflected in attribute #6 until a reset.
Valid range: 0.0.0.0 - 255.255.255.255 (Default =0.0.0.0)
Get Array of Holds the configured value, which will be written to attribute #5
UINT8 after the module has been reset.
Valid range: 0.0.0.0 - 255.255.255.255 (Default =0.0.0.0)
String Meaning
(Multilingual, see page 70)
"Auto" Auto negotiation (default)
"10 HDX" 10Mbit, half duplex
"10 FX" 10Mbit, full duplex
"100HDX" 100Mbit, half duplex
"100FX" 100Mbit, full duplex
String Meaning
(Multilingual, see page 70)
"Auto" Auto negotiation
"10 HDX" 10Mbit, half duplex
"10 FX" 10Mbit, full duplex
"100HDX" 100Mbit, half duplex
"100FX" 100Mbit, full duplex
