CIP Objects
Instance Attributes
Each instance corresponds to an instance within the Application Data Object (for more information, please
consult the general Anybus CompactCom 40 Software Design Guide).
# Name Access
1 Name Get
2 ABCC Data
Get
type
3 No. of Get
Elements
4 Descriptor Get
5 Value Get/Set
6 Max Value Get
7 Min Value Get
8 Default
Get
Value
9 Number of Get
subelements
Attributes #5–8 are converted to/from CIP standard by the module
Anybus CompactCom 40 EtherNet/IP Transparent Ethernet Network Guide
Type Value/Description
SHORT_ Parameter name (Including length)
STRING
Array of USINT Data type of instance value
USINT Number of elements of the specified data type
Array of USINT Bit field describing the access rights for this instance
Bit: Meaning:
0 1 = Get Access
1 1 = Set Access
2 (reserved, set to 0)
3 1 = Write process data mapping possible
4 1 = Read process data mapping possible
5 1 = NVS parameter
6 1 = Data notification enabled
Determined by Instance value
attributes #2,
The maximum permitted parameter value.
#3 and #9
The minimum permitted parameter value.
The default parameter value.
Array of UINT Number of subelements in the ADI. Default value is 1 unless imple-
mented in the application.
The size of the array depends on attribute #3.
