CIP Objects
Instance Attributes
# Name Access
1 Power Man- Get
agement
Command
2 Power Man- Get
agement
Status
3 Client Path Get
4 Number of Get
Power Man-
agement
Modes
5 Power Man- Get
agement
Nodes
6 Sleeping Get
State
Support
Anybus CompactCom 40 EtherNet/IP Transparent Ethernet Network Guide
Type Value/Description
DWORD Collection of bit fields comprising the most recent power management
request.
DWORD Collection of bit fields providing Power Management status information.
Struct of: Specifies the EPATH from this instance (server) to its current owner
(client).
UINT (Path Size of path (in words
Size)
Padded EPATH
(Path)
UINT Number of Power Management Mode array entries in attribute 5.
Array of: Array of low power modes
Struct of: Modes (Array of mode structures)
USINT Minimum Pause Units (Specifies the unit of Minimum Pause Time)
UINT Minimum Pause Time
USINT Resume Units (Specifies the unit of Resume Time)
UINT Resume Time (Required time to transition from the paused stated to the
owned state.
REAL Power Level (Power in kW for this mode)
BOOL Availability (Specifies whether this mode can be entered given the current
device state)
BOOL 0 (Sleeping state not supported)
