CIP Objects
7.15

Ethernet Link Object (F6h)

Category
Extended
Object Description
This object maintains link specific counters and status information for an IEEE 802.3 communications inter-
face. Exactly one instance for each communications interface on the module is supported. Instances for inter-
nally accessible interfaces can also be supported.
See also ..
• Communication Settings, p. 12
• Network Configuration Object (04h), p. 63
Supported Services
Class:
Instance:
Class Attributes
By default, three instances (port 1, port 2 and the internal port) are implemented, meaning that two ports are
activated.
If port 2 is inactivated in the Port 2 State attribute of the Ethernet Host Object (F9h), only one instance (port 1)
should be implemented.
# Name Access
1 Revision Get
2 Max Get
Instance
3 Number of Get
Instances
6 Maximum ID Get
Number
Class
Attributes
7 Maximum ID Get
Number In-
stance
Attributes
Anybus CompactCom 40 EtherNet/IP Transparent Ethernet Network Guide
(Anybus Module Object)
Get_Attributes_All
Get_Attribute_Single
Get_Attributes_All
Get_Attribute_Single
Set_Attribute_Single
Get_And_Clear
Type Value
UINT 0004h (Object revision)
UINT 1 or 3 (Maximum instance number)
UINT 1 or 3 (Number of instances)
UINT 7 (The attribute number of the last implemented class attribute.)
UINT 11 (The attribute number of the last implemented instance attribute.)
