Translation Of Status Codes - Anybus CompactCom 40 Network Manual

CIP Objects
7.2

Translation of Status Codes

If an error occurs when an object is requested from the application, an error code is returned.
These Anybus CompactCom error codes are translated to CIP status codes according to the ta-
ble below.
Anybus CompactCom 40 Error Code
Value
00h
01h
02h
03h
04h
05h
06h
07h
08h
09h
0Ah
0Bh
0Ch
0Dh
0Eh
0Fh
10h
11h
12h
13h
14h
FFh
Other
For further information about the Anybus CompactCom error codes, please consult the Anybus
CompactCom 40 Software Design Guide.
Anybus CompactCom 40 EtherNet/IP Transparent Ethernet Network Guide
Error
Reserved
Reserved
Invalid message format
Unsupported object
Unsupported instance
Unsupported Command
Invalid CmdExt(0)
Invalid CmdExt(1)
Attribute not settable
Attribute not gettable
Too Much Data
Not Enough Data
Out of range
Invalid state
Out of resources
Segmentation failure
Segmentation buffer overflow
Value too high
Value too low
Attribute controlled
Message channel too small
Object Specific Error
-
CIP Status Code
Value Status
1Eh Embedded service error
1Eh Embedded service error
1Eh Embedded service error
05h Path destination unknown
05h Path destination unknown
08h Service not supported
14h Depending on Anybus CompactCom Service return-
ing this reply, e.g. attribute not supported
-
Depending on Anybus CompactCom Service return-
ing this reply
0Eh Attribute not settable
2Ch Attribute not gettable
15h Too much data
13h Not enough data
09h Invalid attribute value
0Ch Object state conflict
02h Resource unavailable
1Eh Embedded service error
23h Buffer overflow
09h Invalid attribute value
09h Invalid attribute value
0Fh A permission/privilege check failed
11h Reply data too large
1Fh Vendor specific error. No additional error codes will
be sent on EtherNet/IP
1Eh Embedded service error
