CIP Objects
Interface Flags
Bit Name
0 Link status
1 Half/full duplex
2 - 4 Negotiation Status
5 Manual Setting requires
Reset
6 Local Hardware Fault
7-31 (reserved)
Interface State
This attribute indicates the current operational state of the interface.
Description
Value
0 Unknown interface state.
1 The interface is enabled and is ready to send and receive data.
2 The interface is disabled.
3 The interface is testing.
Admin State
This attribute controls the administrative setting of the interface state.
Description
Value
0 (reserved)
1 Enable the interface.
2 Disable the interface.
3-255 (reserved)
Anybus CompactCom 40 EtherNet/IP Transparent Ethernet Network Guide
Description
Indicates whether or not the Ethernet 802.3 communications interface is connected to
an active network.
Value: Meaning:
0 Inactive link
1 Active link
Indicates the duplex mode currently in use.
Value: Meaning:
0 Half duplex
1 Full duplex
Indicates the status of link auto-negotiation.
Value: Meaning:
0 Auto-negotiation in progress.
1 Auto-negotiation and speed detection failed (using default values)
(Recommended default values are 10 Mbps, half duplex)
2 Auto negotiation failed but detected speed (using default duplex value)
3 Successfully negotiated speed and duplex.
4 Auto-negotiation not attempted. Forced speed and duplex.
Value: Meaning:
0 Interface can activate changes to link parameters during runtime
1 Reset is required in order for changes to have effect
Value: Meaning:
0 No local hardware fault detected
1 Local hardware fault detected
Set to 0.
