Appendix G: Backward Compatibility
EtherNet/IP functionality
Max Message
Connections
EtherNet/IP
Encapsulation
Sessions
G.4.3 EDS file (Electronic Datasheet file used by configuration tool)
EDS file Generator Tool
An EDS-generator for automatic EDS-file generation up to date with the differences below. The
EDS-generator only works with the 40-series, version 1.30 and later.
The generator can be downloaded from www.anybus.com/starterkit40: .
Keywords
The following keywords differs between the 30-series and the 40-series. The EDS generator re-
flects this change.
Keyword
Capacity->MaxCIPConnections
Capacity->MaxMsgConnections
Capacity->MaxIOConnections
Anybus CompactCom 40 EtherNet/IP Transparent Ethernet Network Guide
The maximum number of simultaneous Class 3 connections are 16 in the 30-
series and 6 in the 40-series.
No change is needed in the host application.
The maximum number of simultaneous encapsulation sessions are 48 in the 30-
series and 15 in the 40-series.
No change is needed in the host application.
Comments
Removed in 40-series – replaced by: MaxMsgCon-
nections and MaxIOConnections (see below)
New keyword in the 40-series, Value: 6
New keyword in the 40-series, Value: 4
