CIP Objects
Instance Attributes
# Name Access
1 Parameter Get/Set
Value
2 Link Path Get
Size
3 Link Path Get
4 Descriptor Get
5 Data Type Get
6 Data Size Get
7 Parameter
Get
Name String
8 Units String Get
9 Help String Get
10 Minimum Get
Value
11 Maximum Get
Value
12 Default Get
Value
13 Scaling
Get
Multiplier
14 Scaling Get
Divisor
15 Scaling Base Get
16 Scaling Get
Offset
17 Multiplier Get
Link
18 Divisor Link Get
19 Base Link Get
20 Offset Link Get
21 Decimal Get
Precision
Anybus CompactCom 40 EtherNet/IP Transparent Ethernet Network Guide
Type Value/Description
Specified in at- Actual value of parameter
tributes 4, 5 & 6.
This attribute is read-only if bit 4 of Attribute #4 is true
USINT 0007h (Size of link path in bytes)
Packed EPATH 20 A2 25 nn nn 30 05h
(Path to the object from where this parameter's value is retrieved, in this
case the ADI Object)
WORD Bit: Contents:
0 Supports Settable Path (N/A)
1
Supports Enumerated Strings
2 Supports Scaling (N/A)
3 Supports Scaling Links (N/A)
4
Read only Parameter
5 Monitor Parameter (N/A)
6 Supports Extended Precision Scaling (N/A)
USINT Data type code
USINT Number of bytes in parameter value
SHORT_ Name of the parameter, truncated to 16 chars
STRING
SHORT_ "" (default string)
STRING
SHORT_
STRING
(Data type) Minimum value of parameter
The Data Type is defined in attribute 5.
(Data type) Maximum value of parameter
The Data Type is defined in attribute 5.
(Data type) Default value of parameter
The Data Type is defined in attribute 5.
UINT 0001h
UINT
UINT
INT 0000h
UINT
UINT
UINT
UINT
USINT 00h
