Anybus Module Objects
8.8

CIP Port Configuration Object (0Dh)

Category
Extended
Object Description
This object is used to populate and enumerate the CIP Port Object (see
work side. Basically, this is a matter of creating and updating instances and attributes which shall represent a
CIP Port within the host application. This process is necessary in case support for Unconnected CIP Routing
has been enabled (see EtherNet/IP Host Object (F8h), p.
Each instance within this object corresponds to an instance in the CIP Port Object. The object supports up to
8 instances, where instance #1 is dedicated to the local TCP port, enabling the host application to implement
up to 7 additional ports. Instance #1 will automatically be populated with default values, however it is possible
for the host application to customize instance attributes #2 and #4.
Apart from attribute #7, it is possible to write to the instance attributes only during setup. The host application
is responsible for keeping instance attribute #7 updated for all ports located within the host application.
Note that the module does not take over the host application responsibility for error control; the
module will not verify that the data set by the host application is correct.
Supported Commands
Object:
Instance:
Object Attributes (Instance #0)
# Name
1 Name
2 Revision
3 Number of instances
4 Highest instance no.
11 Max. no. of instances
Anybus CompactCom 40 EtherNet/IP Transparent Ethernet Network Guide
Get_Attribute
Create
Delete
Get_Attribute
Set_Attribute
Access Data Type
Get Array of
CHAR
Get UINT8
Get UINT16
Get UINT16
Get UINT16
Port Object (F4h), p.
88, Instance Attribute #17).
Value
"Network Ethernet"
01h
-
-
0008h
74 (144)
48) on the net-
SCM-1202-019-EN 1.6
