Anybus Module Objects
8.7

Network Ethernet Object (0Ch)

Category
Extended
Object Description
This object provides Ethernet-specific information to the application.
The object has three instances, each corresponding to a port:
Instance # Port
1 Internal port
2 Port 1
3 Port 2
Each instance provides statistic counters for the port. This information can e.g be presented on internal web
pages, if present, using the JSON script language.
Instance attribute #1 is reserved and used for backwards compatibility with earlier applications.
Supported Commands
Object:
Instance:
Object Attributes (Instance #0)
# Name
1 Name
2 Revision
3 Number of instances
4 Highest instance no.
Instance Attributes (Instance #1)
# Name
1 MAC Address
2 (Reserved)
3 (Reserved)
4 MAC Address
5
Interface Counters
6 (Reserved)
Anybus CompactCom 40 EtherNet/IP Transparent Ethernet Network Guide
Get_Attribute
Get_Attribute
Access Data Type
Get Array of
CHAR
Get UINT8
Get UINT16
Get UINT16
Access Data Type
Get Array of
UINT8
Get Array of
UINT8
Get Array of
UINT32
Value
"Network Ethernet"
01h
3
3
Description
Reserved, used for backwards compatibility.
(Device MAC address.)
(See also Ethernet Host Object (F9h), p.
Device MAC address
Array containing MIB-II interface counters (rfc1213)
See table below for array indices.
72 (144)
97)
