Anybus Module Objects
Instance Attributes (Instance #1)
# Name
1 Port Type
2 Port Number
3 Link Path
4 Port Name
-
5
-
6
7 Node Address
8 Port Node Range
Anybus CompactCom 40 EtherNet/IP Transparent Ethernet Network Guide
Access Data Type Description
Set UINT16 Enumerates the port (See CIP specification, available from
odva.org)
Set UINT16 CIP port number associated with this port
Set Array of Logical path segments which identify the object for this port.
UINT8
Set Array of String (max. no. of characters is 64) which names the port.
CHAR
- -
(reserved)
- -
(reserved)
Set Array of Node number of this device on port. The data type restricts the
UINT8 range to a Port Segment. The encoded port number must match
the value specified in attribute #2.
A device which does not have a node number on the port can
specify a zero length node address within the Port Segment (i.e.
10h 00h).
In case the node address changes during runtime, the host ap-
plication is responsible for updating this attribute as well.
Set Struct of: Minimum and maximum node number on port.
Support for this attribute is conditional; the attribute shall be sup-
UINT16
(Min) ported provided that the node number can be reported within the
range of the data type (e.g. DeviceNet). If not (as is the case
UINT16
with networks such as EtherNet/IP which uses a 4 byte IP ad-
(Max)
dress), the attribute shall not be supported.
75 (144)
