Anybus CompactCom 40 Network Manual page 100

Host Application Objects
# Name Ac-
cess
9 Port 1 MAC Get
address
10 Port 2 MAC Get
address
11 Enable ACD Get
12 Port 1 State Get
13 Port 2 State Get
14 (reserved)
15 Enable reset Get
from HICP
16 IP configuration Set
Anybus CompactCom 40 EtherNet/IP Transparent Ethernet Network Guide
Data Type Default
Value
-
Array of
UINT8
-
Array of
UINT8
BOOL True
(Enabled)
ENUM 0 (Enabled)
ENUM 0 (Enabled)
BOOL 0 = False
Struct of: N/A
UINT32 (IP
address)
UINT32
(Subnet
mask)
UINT32
(Gateway)
Comment
Note: This attribute is only valid for PROFINET devices.
6 byte MAC address for port 1 (mandatory for the LLDP
protocol).
This setting overrides any Port MAC address in the host
PROFINET IO Object.
Do not implement this attribute if the preprogrammed Mac
address is to be used.
Note: This attribute is only valid for PROFINET devices.
6 byte MAC address for port 2 (mandatory for the LLDP
protocol).
This setting overrides any Port MAC address in the host
PROFINET IO Object.
Do not implement this attribute if the preprogrammed Mac
address is to be used.
Enable/Disable ACD protocol.
If ACD functionality is disabled using this attribute, the
ACD attributes in the CIP TCP/IP object (F5h) are not
available.
The state of Ethernet port 1.
• This attribute is not read by EtherCAT and Ethernet
POWERLINK devices, where Port 1 is always
enabled.
• This attribute is not used by PROFINET and Ethernet
POWERLINK
00h: Enabled
01h: Disabled.
The port is treated as existing. References to
the port can exist, e.g. in network protocol or
on website.
The state of Ethernet port 2.
• This attribute is not read by EtherCAT and Ethernet
POWERLINK devices, where Port 2 is always
enabled.
• This attribute is not used by PROFINET
00h: Enabled
01h: Disabled.
The port is treated as existing. References to
the port can exist, e.g. in network protocol or
on website.
02h: Inactive.
The attribute is set to this value for a device
that only has one physical port. All two-port
functionality is disabled. No references can
be made to this port.
Note: This functionality is available for Ether-
net/IP and Modbus-TCP devices.
Enables the option to reset the module from HICP.
Whenever the configuration is assigned or changed, the
Anybus CompactCom module will update this attribute.
98 (144)
SCM-1202-019-EN 1.6
