9.2.8 Number of Pumps in each Well
If more than one well is configured, consecutive prompts are displayed requesting the number of pumps in
each well.
NOTE: The number of pumps available for the system is limited to 3, 6 or 9 depending on the software
and hardware options purchased.
NOTE: If more than 3 pumps or more than 1 well are selected during the Setup Wizard, then no I/O
defaults will be applied.
9.2.9 Select Fault Input Sensor Type
The digital inputs can be setup to handle either a Flygt FLS sensor, or a Thermal/Seal type sensor direct
from the pumps.
NOTE: This specific pump fault input is identified because the FLS uses one input, whereas a typical
thermistor/seal combination uses two inputs. The answer to this question establishes a default
connection diagram
If the pumps have neither a Flygt FLS sensor nor a Thermal/Seal type sensor, choose None. (After the
MultiSmart is configured, it may be necessary to unassign some of the default digital inputs or faults that are
not used in the panel. Refer to Section 9.3 at the end of this Quick Commissioning Section).
9.2.10 Configure Phase to Phase Voltage
A phase to phase pump supply voltage is required in order for the voltage protection functionality to work
correctly. Either select one of the options, or enter a custom voltage. The over-voltage, under-voltage and
phase fail thresholds are then automatically configured.
To modify the threshold settings after the setup wizard is completed, go to:
9.2.11 Choose DNP3 Configuration (Reservoir Setup Only)
One of three standard DNP3 configurations must be chosen when setting up the MultiSmart as a Reservoir
monitor. The selected configuration sets the method of communications between the reservoir and the
remote pump station.
Configuration B is the preferred method. It sets up the DNP3 configuration for situations where a direct
communications link between the pump station and reservoir station exists.
Configurations A and C are used where a direct communications link is not present. Instead, these
configurations setup the MultiSmart to receive the level via a DNP Master (MTU).
See Section 21 for more information.
9.2.12 Accepting New Configuration & Resetting Controller
The final commissioning screen displays a summary of the major settings entered. Check the configuration
carefully and press the Yes button if it is correct. All current settings are replaced by the new configuration.
The controller restarts with the new settings. This process takes a few minutes to complete.
MultiSmart_IO_Manual_R20
and select the parameter to modify (see section 18).
