Fault Name
IO Unit – Analog Inputs
IO Unit 1 Ain 1 Over Range
IO Unit 1 Ain 1 Under Range
IO Unit 1 Ain 2 Over Range
IO Unit 1 Ain 2 Under Range
Generator faults (No default Sources are linked to these faults)
Generator Running
Generator Fault
Rain Gauge Fault
NOTES:
1. The Low Range Limit is found under: Advanced / IOModule / Unit / Unit 01 / Probe / Probe01 / Duo Probe / Low Range Limit.
2. These are the default inputs only when Thermal/Seal inputs are selected as part of the Setup Wizard.
3. These are the default inputs only when Flygt FLS inputs are selected as part of the Setup Wizard.
4. These faults are specific to each profile.
5. The Inhibit faults (Station & Pump) can be overridden by a digital input (if configured) (e.g. Station Inhibit Override or Pump x Inhibit))
Page 240 of 260
Description
percentage of the expected flow, to give a warning to the operator
Analog input current is greater than the specified maximum
Analog input current is less than the specified minimum
Analog input current is greater than the specified maximum
Analog input current is less than the specified minimum
Generator supply is currently being used
Generator is faulty
A predefined fault for a rain gauge
MultiSmart Installation & Operation Manual
Default
Default
Section
Setting
Status
Reference
20mA
On
-
4mA
On
-
20mA
On
-
4mA
On
-
-
Off
5.4.3.4
-
Off
5.4.3.4
-
Off
-
MultiSmart_IO_Manual_R20
