After the source is selected, press Back, and repeat the process for each digital output. The sources listed in
this setup screen include:
Any Fault
Remote Source
High High Level Alarm
High Level Alarm
Low Level Alarm
Low Low Level Alarm
Any Level Alarm
Any High Level Alarm
Any Low Level Alarm
Primary Level Fault
Backup Level Fault
Well Mixer Active
Well Washer Active
Table 17 – Digital Output Sources
*Application failure is the internal watchdog functionality.
If the desired source cannot be found in this list, press the Advanced button, which then displays the Tag
Browser and allows the selection of any digital tag within the system.
Page 132 of 260
MultiSmart Installation & Operation Manual
Probe 1 Sensor Fault
Probe 2 Sensor Fault
Pump 1 Call to Run
-etc to number of pumps
Pump 1 Reversing
-etc to number of pumps
Any Pumps Running
All Pumps Running
No Pumps Running
Pump 1 Unavailable
-etc to number of pumps
All Pumps Available
Any Pumps Unavailable
All Pumps Unavailable
Any Pump Faulted
All Pumps Faulted
Pump 1 Off
-etc to number of pumps
Pump 1 Off or Unavailable
-etc to number of pumps
Any Pumps Off
All Pumps Off
Any Pumps Off or
Unavailable
All Pumps Off or
Unavailable
Over Voltage
Under Voltage
DC Over Voltage
DC Under Voltage
Battery Over Voltage
Battery Under Voltage
Test Battery
Application Failure*
Modem Reboot
AIN1 Over Range
AIN1 Under Range
AIN2 Over Range
AIN2 Under Range
