MultiSmart Installation & Operation Manual
Part 2 – Installation & Commissioning
WARNING:
Do not use this unit in environments that may contain flammable/explosive or chemically aggressive
gases or powders.
6

Mounting Instructions

The MultiSmart pump station manager is mounted on a standard DIN rail on a panel inside an enclosure.
The operator interface is usually mounted on the (dead) front door of the enclosure. The two units are
connected together with the cable supplied.

6.1 Mounting the Operator Interface Display

The operator interface (LCD) is mounted to the door with 8 x M4 hex head screws (supplied). A 25mm (1")
hole must be cut to accommodate the cable connecting the interface to the controller. Drilling dimensions
are given below. Note, this drawing is not to scale. (See Appendix B for a mounting template).
MultiSmart_IO_Manual_R20
Page 33 of 260
