15 Profiles

The MultiSmart can have multiple sets of fully programmable profiles. Each profile can have independent
setpoints and a few specific pump control parameters (e.g. maximum pumps to run). These can be used by
an operator to switch the pump station into another mode of operation simply by selecting one profile.
Profiles can be selected via the following methods:
•
User interface
•
A digital input or any digital tag (e.g. an alarm condition)
•
A timer (e.g. time of day and multiple timers can be setup)
•
SCADA
•
Logic engine script or ISaGRAF program
Multiple profiles can be configured by the user. This flexibility allows efficient pump station control both
locally and remotely. The MultiSmart is supplied with three profiles pre-configured:
•
Default
Suitable for most sewerage applications as shipped from the factory. It is intended to be the
standard mode of operation for the pump station.
•
Spill Management
A set of peak levels for use in emergency spill management situations. The pump station can be
switched to this profile rather than manually setting new levels.
•
GenSet/Load Shedding
Uses a set of levels designed to limit how long pumps are run in order to minimize the load. This
profile can be used in power outage situations where a generator set is being used temporarily.
There are also 3 generic profiles (profiles 4-6) that can be named and configured according to user
requirements.
