4.2 Intuitive Operator Interface

The MultiSmart has screens which have been designed for operators of pump stations. The operator can see
at a glance:
•
Level
•
Pump mode
•
Pump availability
•
Detailed fault information
•
Date/time of each fault occurring and clearing
•
Single or 3-phase supply, DC supply
•
Fault and event history (up to 50,000 records, or millions of records with SD card)
•
Accumulators (starts, hours, faults, etc)
•
Pump efficiency (requires energy monitoring, motor protection and flow enabled)
•
Status of all I/O
•
Status of a communications link
•
Duration to Overflow

4.3 Intuitive Engineering Interface

The product has clear menu screens for altering:
•
Pump set points
•
Alarm set points
•
Delays
•
Alternation and grouping
•
Level device and backup level device
•
Number of pumps
•
I/O and fault configuration
•
Supply protection
•
Energy Monitoring and Motor protection (where installed)
•
Station optimization parameters (max run time, max off time, max starts per hour, plus many more)
•
Data logging parameters
•
Communications
•
Profiles
