MultiSmart Installation & Operation Manual
7.5.4.1
CAN Bus Settings
Figure 53 – Connecting Expanded I/O
NOTE:
The CAN Bus Termination is set to ON for standalone MultiSmart units. Termination is only set to ON
when this device is the LAST device on the CAN Bus network.
Hardware
Configuration
Master device only
Master + Slave
Master + Slave(s)
Table 4 – Can BUS and Can ID Settings
Figure 54 – CAN Bus Settings - Single unit only
Figure 56 – CAN Bus Settings – Intermediate Slave Unit
MultiSmart_IO_Manual_R20
Master Unit
CAN Bus
CAN
CAN Bus
Termination
ID
Termination
ON
1
OFF
1
OFF
1
First Slave
Second Slave
CAN
CAN Bus
ID
Termination
n/a
n/a
n/a
ON
2
n/a
OFF
2
ON
Figure 55 – CAN Bus Settings – Master Unit
Figure 57 – CAN Bus Settings – Last Slave Unit
Comment
CAN
ID
n/a
Default setting
n/a
Single slave device
3
Multiple slave devices
Page 53 of 260
