19 Datalogger

The MultiSmart comes with a sophisticated datalogger. The results can be viewed by pressing the History
button from the main screen. Also, the data can be downloaded onto a laptop and viewed via Excel, Access,
or any other reporting/database tool.
The primary datalogger – called the Event Logger - stores faults and events and is fully configurable.
There are additional datalogging options (which are explained later in this section):
•
Crisis Logging
•
Interval Logging
The datalogger stores approximately 50,000 events and faults. Each event or fault is date/time stamped.
By default, the following are configured to be logged:
•
All faults
•
Level
•
Pump starts/stops
•
Pump mode changes
•
Changes to analog inputs and level by more than 5%
•
Voltage changes of more than 10 V
•
Flow values and overflow events – if the optional flow module is installed
•
Profile changes
•
Pump power factor
•
SMS send/receive
•
Level Simulation activates/deactivates
•
Pump efficiency yesterday
•
Energy accumulators per pump
•
IRT changes
•
Single or 3-phase current changes
•
User logins, invalid logins, invalid administrator logins
•
Unforced restarts (watchdog)
•
Temperature changes of more than 10°C
