Configuring if-match clauses

You can either specify no if-match clauses or multiple if-match clauses for a routing policy node. If
no if-match clause is specified for a permit node, all routes can pass the node. If no if-match clause
is specified for a deny node, no routes can pass the node.
The if-match clauses of a routing policy node have a logical AND relationship. A route must meet all
if-match clauses before it can be executed by the apply clauses of the node. If an if-match
command exceeds the maximum length, multiple if-match clauses of the same type are generated.
These clauses have a logical OR relationship. A route only needs to meet one of them.
To configure if-match clauses:
Step
1. Enter system view.
2. Enter routing policy node view.
3. Match routes whose
destination, next hop, or source
address matches an ACL or
prefix list.
4. Match BGP routes whose
AS_PATH attribute matches a
specified AS path list.
5. Match BGP routes whose
COMMUNITY attribute
matches a specified
community list.
6. Match routes having the
specified cost.
7. Match BGP routes whose
extended community attribute
matches a specified extended
community list.
Command
system-view
route-policy route-policy-name
{ deny | permit } node node-number
•
Match IPv4 routes whose
destination, next hop, or source
address matches an ACL or
IPv4 prefix list:
if-match ip { address |
next-hop | route-source } { acl
ipv4-acl-number | prefix-list
prefix-list-name }
•
Match IPv6 routes whose
destination, next hop, or source
address matches an ACL or
IPv6 prefix list:
if-match ipv6 { address |
next-hop | route-source } { acl
ipv6-acl-number | prefix-list
prefix-list-name }
if-match as-path
as-path-number&<1-32>
if-match community
{ { basic-community-list-number |
name comm-list-name }
[ whole-match ] |
adv-community-list-number }&<1-32
>
if-match cost cost-value
if-match extcommunity
ext-comm-list-number&<1-32>
506
Remarks
N/A
N/A
By default, no ACL or prefix
list match criterion is
configured.
If the ACL used by an
if-match clause does not
exist, the clause is always
matched. If no rules of the
specified ACL are matched
or the match rules are
inactive, the clause is not
matched.
The ACL specified in an
if-match clause must be a
non-VPN ACL.
All IPv6 routes match a node
if the if-match clauses of the
node use only IPv4 ACLs.
All IPv4 routes match a node
if the if-match clauses of the
node use only IPv6 ACLs.
By default, no AS path match
criterion is configured.
By default, no COMMUNITY
match criterion is matched.
By default, no cost match
criterion is configured.
By default, no extended
community list match
criterion is configured.
