EAS20091
WIRING DIAGRAM
YZF-R25 2014
1. Main switch
2. Diode 1
3. Ignition fuse
4. Signaling system fuse
5. Backup fuse
6. Headlight fuse
7. Radiator fan motor fuse
8. AC magneto
9. Crankshaft position sensor
10. Rectifier/regulator
11. Battery
12. Engine ground
13. Main fuse
14. Starter relay
15. Starter motor
16. Diode 2
17. Diode 3
18. Starting circuit cut-off relay
19. Diode 4
20. Fuel pump
21. Fuel sender
22. Throttle body sensor assembly
23. Intake air pressure sensor
24. Intake air temperature sensor
25. Throttle position sensor
26. O sensor
2
27. Lean angle sensor
28. Speed sensor
29. ECU (engine control unit)
30. Ignition coil #1
31. Spark plug
32. Ignition coil #2
33. Fuel injector #1
34. Fuel injector #2
35. Air induction system solenoid
36. ISC (idle speed control) valve
37. Coolant temperature sensor
38. Yamaha diagnostic tool coupler
39. Meter assembly
40. Oil pressure warning light
41. Neutral indicator light
42. Tachometer
43. Multi-function meter 1
44. Engine trouble warning light
45. Shift timing indicator light
46. Multi-function meter 2
47. High beam indicator light
48. Turn signal indicator light
49. Meter light
50. Oil pressure switch
51. Gear position switch
52. Turn signal relay
53. Handlebar switch (left)
54. Pass switch
55. Dimmer switch
56. Horn switch
57. Horn
58. Clutch switch
59. Turn signal switch
60. Rear turn signal light (left)
61. Rear turn signal light (right)
62. Front turn signal light (left)
63. Front turn signal light (right)
64. Headlight (right)
65. Headlight (left)
66. Auxiliary light
67. Handlebar switch (right)
68. Front brake light switch
69. Start switch
70. Engine stop switch
71. Rear brake light switch
72. Tail/brake light
73. License plate light
74. Tail/brake light, License plate
light connector
75. Headlight relay
76. Radiator fan motor relay
77. Radiator fan motor
A. Wire harness
B. Negative battery sub-wire har-
ness
C. Oil pressure switch sub lead
EAS30613
COLOR CODE
B Black
Br Brown
Ch Chocolate
Dg Dark green
G Green
Gy Gray
L Blue
O Orange
P Pink
R Red
Sb Sky blue
W White
Y Yellow
B/L Black/Blue
B/R Black/Red
B/W Black/White
B/Y Black/Yellow
Br/R Brown/Red
Br/W Brown/White
G/B Green/Black
G/R Green/Red
G/W Green/White
G/Y Green/Yellow
Gy/G Gray/Green
Gy/R Gray/Red
L/B Blue/Black
L/W Blue/White
L/Y Blue/Yellow
P/B Pink/Black
P/L Pink/Blue
P/W Pink/White
R/B Red/Black
R/G Red/Green
R/L Red/Blue
R/W Red/White
R/Y Red/Yellow
Sb/W Sky blue/White
W/R White/Red
W/Y White/Yellow
Y/B Yellow/Black
Y/G Yellow/Green
Y/L Yellow/Blue
Y/R Yellow/Red
Y/W Yellow/White
