OWNER'S MANUAL
YZF-R6
MOTORCYCLE
Read this manual carefully before oper-
ating this vehicle.
YZFR6J
YZFR6JC
LIT-11626-31-54
BN6-28199-11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YZF-R6 2017 and is the answer not in the manual?

Questions and answers

Summary of Contents for Yamaha YZF-R6 2017

  • Page 1 OWNER’S MANUAL YZF-R6 MOTORCYCLE Read this manual carefully before oper- ating this vehicle. YZFR6J YZFR6JC LIT-11626-31-54 BN6-28199-11...
  • Page 2 EAU10044 Operating, servicing and maintaining a passenger vehicle or off-road vehicle can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. To minimize exposure, avoid breathing exhaust, do not idle the engine except as necessary, service your vehicle in a well-ventilated area and wear gloves or wash your...
  • Page 3 EAU10084 Congratulations on your purchase of the Yamaha YZFR6J / YZFR6JC. This model is the result of Yamaha’s vast experience in the production of fine sporting, tour- ing, and pacesetting racing machines. It represents the high degree of craftsman- ship and reliability that have made Yamaha a leader in these fields.
  • Page 4 *Product and specifications are subject to change without notice. EAU10194 YZFR6J / YZFR6JC OWNER’S MANUAL ©2017 by Yamaha Motor Corporation, U.S.A. 1st edition, August 2017 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Corporation, U.S.A.
  • Page 5: Table Of Contents

    Table of contents Location of important labels....1-1 Shifting..........7-3 Engine break-in....... 7-4 Safety information ......2-1 Parking..........7-5 Description ........3-1 Periodic maintenance and Left view ..........3-1 adjustment ........8-1 Right view........3-2 Owner’s tool kit....... 8-2 Controls and instruments....3-3 Periodic maintenance chart for the emission control system....
  • Page 6 Vehicle data recording....11-3 Reporting safety defects ....11-4 Motorcycle noise regulation ..11-5 Maintenance record ..... 11-6 YAMAHA MOTOR CORPORATION, U.S.A. 2015 AND LATER MODEL STREET & DUAL-PURPOSE MOTORCYCLE LIMITED WARRANTY ......11-7 YAMAHA EXTENDED SERVICE (Y.E.S.) ........11-9 Index..........12-1...
  • Page 7: Location Of Important Labels

    Read and understand all of the labels on your vehicle. They contain important in- formation for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer.
  • Page 8 Location of important labels WARNING NOTICE BEFORE YOU OPERATE THIS VEHICLE, READ Cleaning with alkaline or acid cleaner, gasoline or THE OWNER’S MANUAL AND ALL LABELS. solvent will damage ALWAYS WEAR AN APPROVED MOTORCYCLE windshield. HELMET, eye protection, and protective clothing. Use neutral detergent.
  • Page 9: Safety Information

    Safety information an accident or equipment damage. EAU1028C See page 6-1 for a list of pre-operation checks. Be a Responsible Owner  This motorcycle is designed to As the vehicle’s owner, you are re- carry the operator and a passen- sponsible for the safe and proper oper- ger.
  • Page 10 Safety information  Many accidents involve inexperi- • The passenger should always enced operators. In fact, many op- hold onto the operator, the seat erators who have been involved in strap or grab bar, if equipped, accidents do not even have a cur- with both hands and keep both rent motorcycle license.
  • Page 11 Safety information extra care when riding a motorcycle Avoid Carbon Monoxide Poisoning All engine exhaust contains carbon that has added cargo or accessories. monoxide, a deadly gas. Breathing Here, along with the information about carbon monoxide can cause head- accessories below, are some general aches, dizziness, drowsiness, nausea, guidelines to follow if loading cargo to confusion, and eventually death.
  • Page 12 Genuine before using it to make sure that it Yamaha accessories, which are avail- does not in any way reduce able only from a Yamaha dealer, have ground clearance or cornering been designed, tested, and approved clearance, limit suspension travel, by Yamaha for use on your vehicle.
  • Page 13 Safety information operator and may limit control handlebars or turn signals, or ability, therefore, such accesso- parts that could break). Choose ries are not recommended. the location for the straps carefully  Use caution when adding electri- so the straps will not rub against cal accessories.
  • Page 14: Description

    Description EAU63371 Left view 1. Fuse box 2 (page 8-36) 2. Fuel tank cap (page 5-17) 3. Spring preload adjuster (page 5-24) 4. Fast compression damping force adjuster (page 5-24) 5. Slow compression damping force adjuster (page 5-24) 6. Rebound damping force adjuster (page 5-24) 7.
  • Page 15: Right View

    Description EAU63391 Right view 1,2,3,4 5,6,7 1. Fuse box 1 (page 8-36) 2. Main fuse (page 8-36) 3. ABS motor fuse (page 8-36) 4. Battery (page 8-34) 5. Spring preload adjuster (page 5-22) 6. Rebound damping force adjuster (page 5-22) 7.
  • Page 16: Controls And Instruments

    Description EAU63401 Controls and instruments 1. Clutch lever (page 5-14) 2. Left handlebar switches (page 5-2) 3. Main switch/steering lock (page 5-1) 4. Multi-function meter unit (page 5-6) 5. Front brake fluid reservoir (page 8-26) 6. Right handlebar switches (page 5-2) 7.
  • Page 17: Special Features

    Special features EAU76422 Mode “A” D-mode (drive mode) Mode “A” offers a sportier engine re- D-mode is an electronically controlled sponse in the low- to mid-speed range engine performance system. This compared to mode “STD”. model has three mode selections: “STD”, “A”, and “B”.
  • Page 18: Traction Control System

    Special features The “ ” indicator light flashes when EAU79732 Traction control system traction control has engaged. You may The traction control system (TCS) notice slight changes in engine and ex- helps maintain traction when acceler- haust sounds when the system has en- ating on slippery surfaces, such as un- gaged.
  • Page 19 (1→2→3→4→5→6). 4. Have a Yamaha dealer check the vehicle and turn off the “ ” TCS settings can also be changed warning light. when moving in straight line if the throt- tle grip is held in a fixed position for two seconds while in 4th, 5th, or 6th gear.
  • Page 20: Quick Shift System

    Special features EAU80010 Quick shift system The quick shift system (QS) allows for full-throttle, clutch lever-less, electron- ically-assisted upshifts. When the shift switch detects motion in the shift pedal (page 5-15), engine power and drive torque are momentarily adjusted to al- low the upshift to occur.
  • Page 21: Instrument And Control Functions

    Instrument and control functions EAU10462 EAU73800 Main switch/steering lock LOCK The steering is locked and all electrical systems are off. The key can be re- moved. To lock the steering LOCK The main switch/steering lock controls the ignition and lighting systems, and is used to lock the steering.
  • Page 22: Handlebar Switches

    Instrument and control functions Push the key in and turn it to “OFF”. EAU66055 Handlebar switches Left 1. Dimmer switch “ ” 2. Pass switch “ ” 3. Traction control system switch “TCS” 4. Turn signal switch “ ” 5. Horn switch “ ”...
  • Page 23 Instrument and control functions EAU79871 EAU73931 Dimmer switch “ ” Drive mode switch “MODE” Set this switch to “ ” for the high See page 4-1 for an explanation of the beam and to “ ” for the low beam. drive mode.
  • Page 24: Indicator Lights And Warning Lights

    EAU11081 High beam indicator light “ ” have a Yamaha dealer check the vehi- This indicator light comes on when the cle. high beam of the headlight is switched If a malfunction is detected, the fuel level warning light will flash repeatedly.
  • Page 25 Do not continue to operate the en- The ABS may not work correctly. If any gine if it is overheating. of the above occurs, have a Yamaha dealer check the system as soon as  For radiator-fan-equipped vehi- possible. (See page 5-16 for an expla- nation of the ABS.)
  • Page 26: Multi-Function Meter Unit

    If the light does not come on during the multi-function meter unit. Changing circuit check, have a Yamaha dealer settings while riding can distract the check the vehicle. operator and increase the risk of an accident.
  • Page 27 Instrument and control functions  display brightness and shift light Clock and lap timer control mode  To switch the multi-function meter unit between miles and kilome- ters, push the “SELECT” button for one second.  The “ ”, “GPS”, and “QS” icons require accessory parts to func- tion.
  • Page 28 Instrument and control functions To view the lap time history 1. Push the “SELECT” button for one second. Lap order history is se- lected (indicated by “L-20” in the lower part of the display), or push the “SELECT” button again to se- lect fast lap history (indicated by “F-20”).
  • Page 29 Instrument and control functions  When the coolant temperature is 4. When you have finished viewing the lap records you can: below 105 °F, “Lo” will be dis-  push the “RESET” button for played. one second to delete that group of lap records.
  • Page 30 Instrument and control functions Transmission gear display TCS display 1. Neutral indicator light “ ” 1. TCS display 2. Transmission gear display This display indicates which traction This display shows the selected gear. control system setting has been se- The neutral position is indicated by “ ” lected: “1”...
  • Page 31 Instrument and control functions Navigating the multi-function dis- TRIP F → km/L, L/100 km or MPG → play Push the “SELECT” button to change AVE _ _ _._ km/L, AVE _ _ _._ L/100 km or AVE _ _ _._ MPG → _ _._ → ODO → between the odometer “ODO”, tripme- TRIP 1 →...
  • Page 32 Instrument and control functions  “MPG”: The distance that can be traveled on 1.0 US gal of fuel un-  To reset the average fuel con- der the current riding conditions is sumption display, push the “RE- shown. SET” button for one second. ...
  • Page 33 Instrument and control functions 3. Turn the key to “ON”, and then re- Display brightness and shift light control mode lease the “SELECT” button after five seconds. 4. Push the “RESET” button to set the brightness level. 5. Push the “SELECT” button to con- firm the setting.
  • Page 34: Clutch Lever

    Instrument and control functions ments of 500 r/min. From 13000 r/min EAU12822 Clutch lever to 18000 r/min, the shift light can be set in increments of 200 r/min. 1. Push the “RESET” button to set the activation point engine speed. 2.
  • Page 35: Shift Pedal

    Instrument and control functions EAU12873 EAU26825 Shift pedal Brake lever The brake lever is located on the right side of the handlebar. To apply the front brake, pull the lever toward the throttle grip. 1. Shift pedal The shift pedal is located on the left side of the motorcycle.
  • Page 36: Brake Pedal

    Instrument and control functions EAU12944 EAU63040 Brake pedal The Yamaha ABS (Anti-lock Brake System) features a dual electronic con- trol system, which acts on the front and rear brakes independently. Operate the brakes with ABS as you would conventional brakes. If the ABS...
  • Page 37: Fuel Tank Cap

    ABS is op- erating. However, special tools are required, so please consult your Yamaha dealer. ECA20100 NOTICE Be careful not to damage the wheel sensor or wheel sensor rotor; other- 1.
  • Page 38: Fuel

    1. Fuel tank filler tube as well as to the exhaust system. 2. Maximum fuel level Your Yamaha engine has been de- signed to use premium unleaded gas- oline with a pump octane number 5-18...
  • Page 39: Fuel Tank Breather Hose And Fuel Tank Overflow Hose

    10% (E10). Gas- ohol containing methanol is not 1. Guide recommended by Yamaha because it 2. Fuel tank overflow hose can cause damage to the fuel system 3. Fuel tank breather hose (U49 models) or vehicle performance problems.
  • Page 40: Catalytic Converters

    Instrument and control functions EAU13447 EAU79900 Catalytic converters Seats This vehicle is equipped with catalytic converters in the exhaust system. Passenger seat EWA10863 WARNING To remove the passenger seat The exhaust system is hot after op- 1. Insert the key into the seat lock, and then turn it clockwise.
  • Page 41 Instrument and control functions Rider seat To remove the rider seat 1. Remove the passenger seat. 2. Pull up the corners on the rear of the rider seat as shown, remove the bolts with the hexagon wrench located under the passenger seat, and then pull the seat off.
  • Page 42: Rear View Mirrors

    Instrument and control functions EAU39672 EAU79921 Rear view mirrors Adjusting the front fork The rear view mirrors of this vehicle can be folded forward or backward for This model is equipped with adjustable parking in narrow spaces. Fold the mir- suspension.
  • Page 43 Instrument and control functions Rebound damping setting: Minimum (soft): 14 click(s) in direction (b)* Standard: 7 click(s) in direction (b)* Maximum (hard): 1 click(s) in direction (b)* * With the adjusting bolt fully turned in direction (a) Compression damping force 1.
  • Page 44: Adjusting The Shock Absorber Assembly

    Instrument and control functions EAU79931 Adjusting the shock absorber Although a damping force adjuster assembly may turn or click beyond the stated mi- nimum settings, such adjustments are This model is equipped with adjustable ineffective and may damage the sus- suspension.
  • Page 45 Instrument and control functions Rebound damping force To increase the rebound damping for- ce and thereby harden the rebound damping, turn the adjusting bolt in di- rection (a). To decrease the rebound damping force and thereby soften the rebound damping, turn the adjusting bolt in direction (b).
  • Page 46  Do not dispose of a damaged or worn-out shock absorber as- sembly yourself. Take the shock absorber assembly to a Yamaha 1. Slow compression damping force adjusting dealer for any service. bolt 5-26...
  • Page 47: Exup System

    Instrument and control functions EAU15283 EAU70641 EXUP system Auxiliary DC connector This model is equipped with Yamaha’s This vehicle is equipped with an auxil- EXUP (EXhaust Ultimate Power valve) iary DC connector. Consult your system. This system boosts engine Yamaha dealer before installing any power by means of a valve that regu- accessories.
  • Page 48: Sidestand

    Therefore, check this system regularly and have a Yamaha dealer repair it if it does not function properly. 5-28...
  • Page 49 5. Push the start switch. Does the engine start? The neutral switch may not be working. The motorcycle should not be ridden until checked by a Yamaha dealer. With the engine still running: 6. Move the sidestand up. 7. Pull the clutch lever.
  • Page 50: For Your Safety - Pre-Operation Checks

    Do not operate the vehicle if you find any problem. If a problem cannot be corrected by the procedures provided in this manual, have the vehicle inspected by a Yamaha dealer. Before using this vehicle, check the following points:...
  • Page 51 • Tighten if necessary. Instruments, lights, • Check operation. — signals and switches • Correct if necessary. • Check operation of ignition circuit cut-off system. Sidestand switch • If system is not working correctly, have Yamaha dealer 5-28 check vehicle.
  • Page 52: Operation And Important Riding Points

    This model is equipped with: there is a control or function you do not  a lean angle sensor to stop the en- understand, ask your Yamaha dealer. gine in case of turnover. Turn the EWA10272 main switch off once before at- WARNING tempting to restart the engine.
  • Page 53: Starting The Engine

    10 km/h (6 mi/h).  The fuel level warning light will stay on if you are low on fuel. ECA24110 NOTICE If a warning or indicator light does not work as described above, have a Yamaha dealer check the vehicle.
  • Page 54: Shifting

    Operation and important riding points EAU16673 and drive train, which are not Shifting designed withstand shock of forced shifting. EAU16682 To start out and accelerate 1. Pull the clutch lever to disengage the clutch. 2. Shift the transmission into first gear.
  • Page 55: Engine Break-In

    5th → 6th: 60 km/h (37 mph) cur during the engine break-in Shift down points: period, immediately have a 6th → 5th: 45 km/h (28 mph) 5th → 4th: 35 km/h (22 mph) Yamaha dealer check the vehi- 4th → 3rd: 25 km/h (16 mph) cle.
  • Page 56: Parking

    Operation and important riding points EAU17214 Parking During and after the engine break-in When parking, stop the engine, and period, the exhaust heat may cause then remove the key from the main discoloration of the exhaust pipe, but switch. this is normal. EWA10312 WARNING ...
  • Page 57: Periodic Maintenance And Adjustment

    If you are not familiar with vehicle ser- vice, have a Yamaha dealer perform service. EWA15123 WARNING Turn off the engine when performing...
  • Page 58: Owner's Tool Kit

    However, additional tools, such as a torque wrench, are necessary to perform certain mainte- nance work correctly. If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you.
  • Page 59: Periodic Maintenance Chart For The Emission Control System

     From 24000 mi (37000 km) or 36 months, repeat the maintenance intervals starting from 8000 mi (13000 km) or 12 months.  Items marked with an asterisk require special tools, data and technical skills, have a Yamaha dealer perform the service. EAU63292 Periodic maintenance chart for the emission control system...
  • Page 60: General Maintenance And Lubrication Chart

    • Perform dynamic inspection Diagnostic system √ √ √ √ √ √ using Yamaha diagnostic tool. check • Check the error codes. 2 * Air filter element • Replace. Every 24000 mi (37000 km) • Check operation. √ √...
  • Page 61 Periodic maintenance and adjustment ROUTINE INITIAL ODOMETER READINGS 1000 mi ITEM 1000 km month • Check bearing assemblies for √ √ √ √ √ √ looseness. 13 * Steering bearings • Moderately repack with lithium- Every 16000 mi (25000 km) soap-based grease.
  • Page 62 Periodic maintenance and adjustment ROUTINE INITIAL ODOMETER READINGS 1000 mi ITEM 1000 km month • Apply Yamaha cable lubricant √ √ √ √ √ √ 28 * Control cables or other suitable cable lubricant thoroughly. • Check operation. • Check throttle grip free play, √...
  • Page 63: Removing And Installing Cowlings And Panels

    Periodic maintenance and adjustment EAU18713 Removing and installing cowl- ings and panels The cowlings and panels shown need to be removed to perform some of the maintenance jobs described in this chapter. Refer to this section each time a cowling or panel needs to be re- moved and installed.
  • Page 64 Periodic maintenance and adjustment 1. Bolt 1. Cowling A To install the cowling 1. Slide the cowling rearward, and then fit the upper projections into the slots. 1. Quick fastener 3. Slide the cowling as shown. 1. Cowling A 2. Slide the cowling as shown. 1.
  • Page 65 Periodic maintenance and adjustment Install the bolts loosely, then install the quick fasteners and quick fastener screw, and then tighten the bolts. 4. Install the panel. Cowling B To remove the cowling 1. Cowling C 1. Remove panel A and cowling A. 2.
  • Page 66 Periodic maintenance and adjustment 1. Cowling C 1. Cowling C 4. Remove the cowling by removing 3. Install the bolts, quick fastener, the upper projections from the and quick fastener screw. slots. Install the bolts loosely, then install the quick fastener and quick fastener screw, and then tighten the bolts.
  • Page 67: Checking The Spark Plugs

    To remove a panel Yamaha dealer. Since heat and depos- Remove the quick fasteners, and then its will cause any spark plug to slowly pull the panel off as shown. erode, they should be removed and...
  • Page 68: Canister (For California)

    Periodic maintenance and adjustment EAU19683 Canister (for California) 1. Spark plug gap 1. Canister Spark plug gap: 2. Canister breather 0.6–0.7 mm (0.024–0.028 in) This model is equipped with a canister Clean the surface of the spark plug to prevent the discharging of fuel vapor gasket and its mating surface, and into the atmosphere.
  • Page 69: Engine Oil And Oil Filter Cartridge

    Periodic maintenance and adjustment 5. Check the dipstick O-ring for EAU3899H Engine oil and oil filter car- damage, and replace it if neces- tridge sary. The engine oil level should be checked 6. If the engine oil is at or below the before each ride.
  • Page 70 1. Engine oil drain bolt 2. Gasket An oil filter wrench is available at a Yamaha dealer. 9. Apply a thin coat of clean engine Skip steps 6–12 if the oil filter cartridge oil to the O-ring of the new oil filter is not being replaced.
  • Page 71 Periodic maintenance and adjustment 1. Torque wrench 1. Shift arm 2. Shift arm bolt Tightening torque: 3. Slot Oil filter cartridge: 4. Shift shaft 17 N·m (1.7 kgf·m, 13 lb·ft) 5. Mark 11. Install the fuel tank breather hose Tightening torque: and overflow hose into the guides, Shift arm bolt: 10 N·m (1.0 kgf·m, 7.4 lb·ft)
  • Page 72 If the oil level warning light flickers or remains on even if the oil level is correct, immediately turn the engine off and have a Yamaha dealer check the vehicle. 18. Turn the engine off, and then check the oil level and correct it if necessary.
  • Page 73: Coolant

    0.25 L (0.26 US qt, 0.22 Imp.qt) Radiator (including all routes): 2.30 L (2.43 US qt, 2.02 Imp.qt) If genuine Yamaha coolant is not avail- able, use an ethylene glycol antifreeze containing corrosion inhibitors for alu- minum engines and mix with distilled water at a 1:1 ratio.
  • Page 74: Air Filter Element

    Have a maintenance and lubrication chart. Yamaha dealer change the coolant. Have a Yamaha dealer replace the air WARNING! Never attempt to remove filter element. the radiator cap when the engine is hot.
  • Page 75: Checking The Engine Idling Speed

    Yamaha dealer. Engine idling speed: 1250–1350 r/min 1. Throttle grip free play Throttle grip free play: 3.0–5.0 mm (0.12–0.20 in) Periodically check the throttle grip free play and, if necessary, have a Yamaha dealer adjust it. 8-19...
  • Page 76: Valve Clearance

    To prevent this from occurring, have your Yamaha dealer check and adjust Tire air pressure the valve clearance at regular intervals. The tire air pressure should be checked and, if necessary, adjusted before each ride.
  • Page 77 This model is equipped with tubeless has a nail or glass fragments in it, or if tires and rubber tire air valves. the sidewall is cracked, have a Yamaha Tires age, even if they have not been dealer replace the tire immediately.
  • Page 78 After extensive tests, only the tires list- ed below have been approved for this model by Yamaha. Front tire: Size: 120/70ZR17M/C (58W) Manufacturer/model: DUNLOP/SPORTMAX D214F BRIDGESTONE/BATTLAX S21F...
  • Page 79: Cast Wheels

    If any damage is found, have a Yamaha dealer replace the wheel. Do not attempt even the smallest repair to the wheel. A de- formed or cracked wheel must be replaced.
  • Page 80: Checking The Brake Lever Free Play

    There should be no free play at the adjusting nut in direction (a). To brake lever end. If there is free play, decrease the clutch lever free have a Yamaha dealer inspect the play, turn the adjusting nut in di- brake system. rection (b).
  • Page 81: Brake Light Switches

    If a brake pad has worn to the point that a wear indicator almost touches the brake disc, have a Yamaha dealer replace the brake pads as a set. 8-25...
  • Page 82: Checking The Brake Fluid Level

    If a brake pad has worn to the point that a wear Rear brake indicator groove almost appears, have a Yamaha dealer replace the brake pads as a set. 1. Minimum level mark Specified brake fluid:...
  • Page 83: Changing The Brake Fluid

     Clean the filler cap before re- EAU22734 Changing the brake fluid moving. Use only DOT 4 brake Have a Yamaha dealer change the fluid from a sealed container. brake fluid every 2 years. In addition,  Use only the specified brake flu- have the seals of the master cylinders id;...
  • Page 84: Drive Chain Slack

    EAU22762 EAU74260 Drive chain slack To adjust the drive chain slack Consult a Yamaha dealer before ad- The drive chain slack should be justing the drive chain slack. checked before each ride and adjusted 1. Loosen the axle nut and the lock- if necessary.
  • Page 85: Cleaning And Lubricating The Drive Chain

    Periodic maintenance and adjustment EAU23026 Cleaning and lubricating the Using the alignment marks on each drive chain side of the swingarm, make sure that The drive chain must be cleaned and both drive chain pullers are in the same lubricated at the intervals specified in position for proper wheel alignment.
  • Page 86: Checking And Lubricating The Cables

    Yamaha dealer at the intervals cated if necessary. If a cable is specified in the periodic maintenance damaged or does not move smoothly, chart.
  • Page 87: Checking And Lubricating The Brake And Shift Pedals

    Periodic maintenance and adjustment EAU44276 EAU23144 Checking and lubricating the Checking and lubricating the brake and shift pedals brake and clutch levers The operation of the brake and shift The operation of the brake and clutch pedals should be checked before each levers should be checked before each ride, and the pedal pivots should be lu- ride, and the lever pivots should be lu-...
  • Page 88: Checking And Lubricating The Sidestand

    The operation of the sidestand should The swingarm pivots must be lubricat- be checked before each ride, and the ed by a Yamaha dealer at the intervals sidestand pivot and metal-to-metal specified in the periodic maintenance contact surfaces should be lubricated and lubrication chart.
  • Page 89: Checking The Front Fork

    If any free over. play can be felt, have a Yamaha [EWA10752] 2. While applying the front brake, dealer check or repair the steer- push down hard on the handle- ing.
  • Page 90: Checking The Wheel Bearings

    (See page 5-20.) hub or if the wheel does not turn This model is equipped with a VRLA smoothly, have a Yamaha dealer (Valve Regulated Lead Acid) battery. check the wheel bearings. There is no need to check the electro- lyte or to add distilled water.
  • Page 91 ECA16531 NOTICE To charge the battery Always keep the battery charged. Have a Yamaha dealer charge the bat- Storing a discharged battery can tery as soon as possible if it seems to cause permanent battery damage. have discharged. Keep in mind that the...
  • Page 92: Replacing The Fuses

    Periodic maintenance and adjustment EAU2370A Replacing the fuses The main fuse, the ABS motor fuse, and fuse box 1 are located under the rider seat. (See page 5-20.) To access the ABS motor fuse, remove the starter relay cover by pulling it up- ward.
  • Page 93: Vehicle Lights

    2.0 A Fuel injection system fuse: check the fuses and then have a 15.0 A Yamaha dealer check the vehicle. If the ABS motor fuse: license plate light does not come on, 30.0 A check and replace the bulb. (See page ABS ECU fuse: 8-38.)
  • Page 94: Replacing The License Plate Light Bulb

    Periodic maintenance and adjustment EAU24314 EAU67131 Replacing the license plate Supporting the motorcycle light bulb 1. Remove the license plate light unit by removing the screws. 1. Maintenance stand (example) Since this model is not equipped with a centerstand, use maintenance stands 1.
  • Page 95: Troubleshooting

    The following troubleshooting charts represent quick and easy procedures for checking these vital systems your- self. However, should your motorcycle require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly.
  • Page 96: Troubleshooting Charts

    Check the vehicle. compression. 4. Compression The engine does not start. There is compression. Have a Yamaha dealer check the vehicle. Operate the electric starter. There is no Have a Yamaha dealer check the vehicle. compression. 8-40...
  • Page 97 Start the engine. If the engine overheats again, The coolant level is have a Yamaha dealer check and repair the cooling system. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended coolant as soon as possible.
  • Page 98: Motorcycle Care And Storage

    Rust and corrosion can develop matte colored finished parts. Be even if high-quality components are sure to consult a Yamaha dealer for used. A rusty exhaust pipe may go un- advice on what products to use be- noticed on a car, however, it detracts fore cleaning the vehicle.
  • Page 99 Motorcycle care and storage  For motorcycles equipped with fected area any longer than in- structed. Also, thoroughly rinse a windshield: Do not use strong the area off with water, immedi- cleaners or hard sponges as ately dry it, and then apply a cor- they will cause...
  • Page 100 For rusting. additional cleaning, use Yamaha Wind- 3. Use a chrome polish to shine shield Cleaner or other quality cleaner. chrome, aluminum and stainless- Some cleaning compounds for plastics steel parts.
  • Page 101: Storage

     To prevent corrosion, avoid damp cellars, stables (because of the presence of ammonia)  Consult a Yamaha dealer for ad- and areas where strong chemi- vice on what products to use. cals are stored.  Washing, rainy weather or humid...
  • Page 102 Motorcycle care and storage der head so that the electrodes are grounded. (This will limit Make any necessary repairs before sparking during the next step.) storing the motorcycle. d. Turn the engine over several times with the starter. (This will coat the cylinder walls with oil.) WARNING! To prevent dam- age or injury from sparking,...
  • Page 103: Specifications

    Specifications Dimensions: 10 30 50 70 90 110 130 ˚F Overall length: 2040 mm (80.3 in) SAE 10W-40 Overall width: 695 mm (27.4 in) SAE 10W-50 Overall height: SAE 15W-40 1150 mm (45.3 in) SAE 20W-40 Seat height: 850 mm (33.5 in) SAE 20W-50 Wheelbase: –20 –10 0...
  • Page 104 Specifications Drivetrain: (Total weight of rider, passenger, cargo and accessories) Primary reduction ratio: Tire air pressure (measured on cold 2.073 (85/41) Final drive: tires): Chain Front: Secondary reduction ratio: 250 kPa (2.50 kgf/cm², 36 psi) 2.813 (45/16) Rear: Transmission type: 290 kPa (2.90 kgf/cm², 42 psi) Constant mesh 6-speed Front wheel:...
  • Page 105 Specifications Ignition system: Headlight fuse: 7.5 A Charging system: Signaling system fuse: AC magneto 10.0 A Battery: Ignition fuse: 15.0 A Model: Radiator fan motor fuse: YTZ7S 15.0 A × 2 Voltage, capacity: Turn signal light fuse: 12 V, 6.0 Ah (10 HR) 7.5 A Bulb wattage: ABS ECU fuse:...
  • Page 106: Consumer Information

    These identification numbers are need- ed when registering the vehicle with the authorities in your area and when ordering spare parts from a Yamaha dealer. 1. Vehicle identification number VEHICLE IDENTIFICATION NUMBER: The vehicle identification number is stamped into the steering head pipe.
  • Page 107 This infor- illustration. This label shows specifica- mation will be needed when ordering tions related to exhaust emissions as spare parts from a Yamaha dealer. required by federal law, state law and Environment Canada. EAU26382 Key identification number 1.
  • Page 108: Diagnostic Connector

     Vehicle status and engine perfor- shown. mance data  Fuel-injection and emission-relat- ed data Yamaha will not disclose this data to a third party except:  With the consent of the vehicle owner  Where obligated by law  For use by Yamaha in litigation ...
  • Page 109: Reporting Safety Defects

    If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Yamaha Motor Corpora- tion, U.S.A. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
  • Page 110: Motorcycle Noise Regulation

    Consumer information EAU26561 Motorcycle noise regulation TAMPERING WITH NOISE CONTROL SYSTEM PROHIBITED: Federal law prohibits the following acts or the causing thereof: (1) The removal or rendering inoperative by any person other than for purposes of maintenance, re- pair, or replacement of any device or element of design incorporated into any new vehicle for the purpose of noise control prior to its sale or delivery to the ultimate purchaser or while it is in use or (2) the use of the vehicle after such device or el- ement of design has been removed or rendered inoperative by any person.
  • Page 111: Maintenance Record

    Consumer information EAU63481 Maintenance record Copies of work orders and/or receipts for parts purchased and installed on your vehicle will be required to document that maintenance has been completed in ac- cordance with the emissions warranty. The chart below is printed only as a re- minder that maintenance work is required.
  • Page 112: Yamaha Motor

    1. Operate and maintain the motorcycle as specified in the appropriate Owner’s Manual, and 2. Give notice to an authorized Yamaha motorcycle dealer of any and all apparent defects within ten (10) days after discovery, and make the machine available at that time for inspection and repairs at such dealer’s place of business.
  • Page 113 CUSTOMER SERVICE If your machine requires warranty service, you must take it to any authorized Yamaha motorcycle dealer within the continental United States. Be sure to bring your warranty registration card or other valid proof of the original date of purchase. If a question or problem arises regarding the warranty, first contact the owner of the dealership.
  • Page 114: Yamaha Extended Service (Y.e.s.)

    • Y.E.S. is flexible. You choose the plan that’s right for you: 12 months, 24 months, 36 months or, on certain models, even 48 months beyond your warranty period. • Y.E.S. is designed and administered by the same Yamaha people who handle your warranty – and it shows in the comprehensive coverage benefits. There are no mileage limitations.
  • Page 115 Yamaha Limited Warranty expires. A special note: If visiting your dealer isn’t convenient, contact Yamaha with your VIN number and we’ll be happy to help you get the Y.E.S. coverage you need. Yamaha Service Marketing P.O.
  • Page 116: Index

    Index Fuel tank breather/overflow hoses ..5-19 Fuel tank cap........5-17 ABS............5-16 Fuses, replacing ........8-36 ABS warning light ........5-5 Air filter element ........8-18 Auxiliary DC connector ......5-27 Handlebar switches........ 5-2 High beam indicator light ....... 5-4 Horn switch ..........5-3 Battery ..........8-34 Brake and clutch levers, checking and lubricating........8-31...
  • Page 117 Index Specifications........10-1 Starting the engine ......... 7-2 Start switch ..........5-3 Steering, checking ....... 8-33 Storage........... 9-4 Supporting the motorcycle....8-38 Swingarm pivots, lubricating....8-32 Throttle grip and cable, checking and lubricating .......... 8-30 Throttle grip free play, checking... 8-19 Tires............
  • Page 119 Genuine Yamaha Accessories – Yamaha only offers accessories that meet our high standards for quality and performance. Buy with confidence, knowing your Genuine Yamaha Accessories will fit right and perform right – right out of the box. Yamalube – Take care of your Yamaha with legendary Yamalube oils, lubricants, and care products.
  • Page 120 PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2017.09-1.1×1 CR...

This manual is also suitable for:

Yzfr6j 2017Yzfr6jc 2017

Table of Contents

Save PDF
