Configuration Mode
Selecting IGP/PGL options for running IGP/PGL files on your printer is
referred to as IGP/PGL configuration. You can select IGP/PGL configuration
parameters by sending commands from the host or by pressing keys on the
control panel.
Chapter 4 describes all the firmware commands.
Chapter 2 shows the control panel menu and describes all of the
configuration parameters. A list of the parameters is shown in Table 1–4.
Table 1–4. IGP/PGL Configuration Mode Options
NOTE:
Parameters marked with an asterisk (*) indicate the factory default value.
The printer must be off–line to enter the configuration structure.
Option
AutoEject
Auto Wrap
Define CR Code
Define LF Code
Introduction
Parameter
Value
DISABLE *
If the last page of a job is only 1/2 full (the data does not fill
the entire page), you can instruct the printer to eject the
ENABLE
page or leave it in the printer. ENABLE causes the printer
to eject the last page after the entire page has been
processed and printed. DISABLE instructs the printer to
eject the page only if you send a Page Eject command or
when the printer receives the next print job.
DISABLE *
Controls automatic "wrapping" of text to the next line
down when the text exceeds the right margin.
ENABLE
DISABLE truncates text beyond the page margin until a
CR or CR + LF is received. ENABLE automatically inserts
a CR + LF after a full print line.
If a proportional spaced font is used, this option is ignored
and the printer does not wrap text.
CR = CR *
When CR = CR + LF, a line feed is automatically inserted
after each CR received, otherwise data passes through
CR = CR + LF
unchanged.
LF = LF *
When LF = CR + LF, a CR is automatically inserted before
each line feed is processed, otherwise data passes through
LF = CR + LF
unchanged.
Comments
1–13
