Logo Mode, Create

Purpose Places the IGP/PGL in the Create Logo mode, where logos can be defined
using the appropriate dot placements. (See TIFF Logo, page 4–92, and
PCX Logo, page 4–81, commands to define logos using TIFF or PCX
data.)
Mode NORMAL
Format (cc)LOGO; logoname; VL; HL [;DISK]
row#; dot; dot1–dot2; dot
END
(cc)
LOGO
logoname
VL
HL
DISK
row#
4–74
The Special Function Control Character.
The Logo command; enter LOGO.
Enter a maximum of 12 alphanumeric characters for
the name of the logo. (Refer to page 4–5 for a list of
allowable Logo Name characters.) All future
references to this logo (Delete Logo or Logo Call
commands) must use this name. If a logo is defined
with the same name as a logo already existing in
memory, the newly defined logo will replace the
existing logo.
Defines the vertical length of the logo grid in dot rows;
enter a value sufficient for the vertical size of the logo,
not exceeding 252. The dot rows are vertically spaced
1/72–inch apart.
Defines the horizontal length of the logo grid in dot
columns; enter a value sufficient for the horizontal size
of the logo, not exceeding 240. On each row, the dots
are horizontally spaced 1/60–inch apart.
Optional parameter to store the logo in the IGP/PGL
internal memory modules. Enter DISK.
Identifies the row number for each row of dots in the
logo. Enter each row number on a separate command
line. Rows are numbered sequentially from top to
bottom.
