2 Appendix

2.3.1 LAN Connector

RJ45 LAN

2.3.2 DSL Connector

RJ11 ADSL

2.3.3 ISDN Connector

RJ45 ISDN

2.3.4 DTE/DCE Connector

DB25 DTE/DCE
20
RJ45 PIN
1
2
3
4
5
6
7
8
RJ11 PIN
1
2
3
4
RJ45 PIN
1
2
3
4
5
6
7
8
LAN
Tx+(input)
Tx-(input)
Rx+(output)
--
--
Rx-(output)
--
--
DSL
Joined to 2
Line
Line
Joined to 3
ISDN
--
--
Tx+ (output)
Rx+(input)
Rx-(input)
Tx-(output)
--
--
Teldat C/S/G/A Routers Family Installation Manual
Teldat S.A.
